PLATE 7000505

PLATE 7000505

PLATE 7000505

1 7000505

  • 7000505 - PLATE
  • Ref. 2-13

2 7000496

  • 7000496 - PLATE

3 6698154

  • 6698154 - LEVER
  • GOVERNOR

4 6687678

  • 6687678 - COLLAR

5 6683021

  • 6683021 - SEAL

6 6687712

  • 6687712 - LEVER

7 6687674

  • 6687674 - NUT

8 6693112

  • 6693112 - LEVER

9 6698155

  • 6698155 - LEVER
  • ENGINE STOP

10 6698156

  • 6698156 - PIN
  • SPRING

11 6683023

  • 6683023 - O-RING

12 6670780

  • 6670780 - SPRING

13 6698157

  • 6698157 - CAP

14 6670457

  • 6670457 - GASKET

15 7024230

  • 7024230 - BOLT
  • FLANGE

16 6693055

  • 6693055 - BOLT

17 6652712

  • 6652712 - BOLT

18 6655228

  • 6655228 - BOLT

19 1DM6

  • 1DM6 - NUT
