(SK235SR-1E) - SHORT RADIUS EXCAVATOR ASN YF04-01501 (1/03-12/04)
/
TUBE YN42H01779P1 (2)

TUBE YN42H01779P1 (2)

TUBE YN42H01779P1 (2)

1 YN42H01779P1

  • YN42H01779P1 - TUBE

2 YF42H01029P1

  • YF42H01029P1 - TUBE

3 YN42H01597D2

  • YN42H01597D2 - HOSE

4 ZD12P03400

  • ZD12P03400 - O-RING
  • 0.139" Thk x 1.296" ID
  • -219
  • Cl 6
  • 90 Duro

5 ZE13X16000

  • ZE13X16000 - FLANGE

6 ZS28C12050

  • ZS28C12050 - CAPSCREW
  • Hex Socket Head
  • M12 x 50mm

7 ZW26K12000

  • ZW26K12000 - LOCK WASHER

8 2432T5924

  • 2432T5924 - CLAMP

9 ZS18C12060

  • ZS18C12060 - SCREW
  • Hex
  • M12 x 60mm

10 ZW26X12000

  • ZW26X12000 - LOCK WASHER

11 ZD12P03800

  • ZD12P03800 - O-RING

12 ZE13X20001

  • ZE13X20001 - CLAMP

13 ZS28C14050

  • ZS28C14050 - CAPSCREW
  • Hex Socket Head
  • M14 x 50mm

14 ZW26K14000

  • ZW26K14000 - LOCK WASHER

15 LC42H01269P1

  • LC42H01269P1 - CLAMP

16 ZS18C12065

  • ZS18C12065 - SCREW
  • Hex
  • M12 x 65mm

17 LS42H01021DC

  • LS42H01021DC - HOSE
