(B90B) - BACKHOE LOADER - TIER 3 (11/10-)
/
SCREW,Hex, M10 x 1.5 x 30mm, Cl 8.8

SCREW,Hex, M10 x 1.5 x 30mm, Cl 8.8

SCREW,Hex, M10 x 1.5 x 30mm, Cl 8.8

1 11106421

  • 11106421 - SCREW
  • Hex
  • M10 x 1.5 x 30mm
  • Cl 8.8

2 11107421

  • 11107421 - BOLT
  • Hex
  • M10 x 60mm
  • Cl 8.8

3 11190574

  • 11190574 - BELLEVILLE WASHER
  • M10 Bolt Size x 20mm OD x 2.3mm Thk

4 11193874

  • 11193874 - BELLEVILLE WASHER
  • M8 Bolt Size x 16mm OD x 1.4mm Thk

5 14496601

  • 14496601 - WASHER
  • 10.5mm ID x 21mm OD x 2mm Thk

6 12577211

  • 12577211 - LOCK NUT
  • M10 x 1.5mm Pitch
  • 12.30mm High
  • Cl 8
  • ZND

7 12601474

  • 12601474 - WAVE WASHER
  • Wave
  • 10.50mm ID x 21.00mm OD x 0.80mm
  • 3.00mm
  • CST
  • DAC

8 16043621

  • 16043621 - BOLT
  • Hex
  • M8 x 1.25 x 25mm
  • Cl 8.8
  • Full Thd

9 15213921

  • 15213921 - BOLT
  • Hex
  • M8 x 1.25 x 70mm

10 14421621

  • 14421621 - SCREW
  • M10 x 130mm
  • Cl 8.8

11 87565328

  • 87565328 - BELT
  • 12.50 mm W x 1300.00 mm L

12 87304910

  • 87304910 - BELT
  • 12.50 mm W x 1175.00 mm L

13 14496534

  • 14496534 - WASHER
  • M8

14 87565321

  • 87565321 - SUPPORT

15 87315441

  • 87315441 - SUPPORT

16 87565322

  • 87565322 - SUPPORT

17 87315446

  • 87315446 - SUPPORT

18 87565326

  • 87565326 - TIGHTENER

19 87315457

  • 87315457 - BELT TENSIONER

20 87315459

  • 87315459 - BLOCK

21 87565346

  • 87565346 - GUARD

22 87315460

  • 87315460 - GUARD

23 16102211

  • 16102211 - NUT
  • M8
  • Cl 10
