(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-)
/
CONTROL VALVE 87658572 (1)

CONTROL VALVE 87658572 (1)

CONTROL VALVE 87658572 (1)

1 87658572

  • 87658572 - CONTROL VALVE

2 87658573

  • 87658573 - CONTROL VALVE

3 83962539

  • 83962539 - HYD CONNECTOR

4 167266

  • 167266 - O-RING
  • 0.116" Thk x 0.924" ID
  • -912
  • Cl 6
  • 90 Duro

5 9992069

  • 9992069 - O-RING
  • 0.07" Thk x 0.614" ID
  • -16
  • Cl 6
  • 90 Duro

6 76089278

  • 76089278 - OPERATING CYLINDER

7 76043921R

  • 76043921R - REMAN-HYD CYLINDER

8 76043921C

  • 76043921C - CORE-HYD CYLINDER

9 895-11012

  • 895-11012 - WASHER
  • 13.5mm ID x 24mm OD x 2.5mm Thk

10 87602786

  • 87602786 - HOSE ASSY.

11 627-12025

  • 627-12025 - BOLT
  • Hex
  • M12 x 1.75 x 25mm
  • Cl 10.9
  • Full Thd

12 87667328

  • 87667328 - FLEXIBLE HOSE

13 87667324

  • 87667324 - FLEXIBLE HOSE

14 4982514

  • 4982514 - CABLE TIE

15 70933135

  • 70933135 - CLAMP

16 76033228

  • 76033228 - COVER PLATE

17 84204211

  • 84204211 - PIN
  • 44.8mm OD x 186mm L

18 76041090

  • 76041090 - SHIM

19 14453181

  • 14453181 - O-RING
  • 0.489" ID x 0.07" Width

20 87667329

  • 87667329 - FLEXIBLE HOSE

21 87667325

  • 87667325 - FLEXIBLE HOSE

22 87381289

  • 87381289 - BHD LOCK NUT

23 X4837565

  • X4837565 - FITTING

24 76041055

  • 76041055 - COLLAR CLAMP

25 12626201

  • 12626201 - WASHER
  • 10.2mm ID x 25mm OD x 3mm Thk

26 627-10030

  • 627-10030 - BOLT
  • Hex
  • M10 x 1.5 x 30mm
  • Cl 10.9
  • Full Thd
