ELBOW 86502180
1 86502180
- 86502180 - ELBOW
- 90°
- JIC
2 86534969
- 86534969 - CLAMP
- Dual-bead
3 86502620
- 86502620 - HYDRAULIC HOSE
- 1.00" ID x 19.00"
- SAE 100R4
4 9712608
- 9712608 - TEMPERATURE SENDER
- 3/8" - 18
- Water Temperature
5 80664
- 80664 - WASHER
- 0.38" ID x 0.88" OD x 0.08" Thk
6 86504073
- 86504073 - SUPPORT
7 9844957
- 9844957 - RESERVOIR
- HYDRAULIC
8 140045
- 140045 - BELLEVILLE WASHER
- M10 Bolt Size x 22mm OD x 1.6mm Thk
9 9842467
- 9842467 - BREATHER
- Filler
- Incl. 10
- 11
10 86631374
- 86631374 - BREATHER
- Tank Filler Breather Assy
- Incl. 10
- 11
11 86628700
- 86628700 - BREATHER
- Cap
12 86625390
- 86625390 - GASKET
- 1.52mm Thk
13 86500940
- 86500940 - SELF-TAP SCREW
- Hex Wash Hd
- #10 x 3/4"
14 86643721
- 86643721 - PRESSURE SWITCH
- Hydraulic Oil Pressure
- 1/8"-27
- Hex
15 86511910
- 86511910 - SCREW
- Pan
- #8 - 32 x 1/4"
16 86500111
- 86500111 - HYDRAULIC HOSE
- 0.50" ID
- 0.75" ID x 5.00"
- SAE 30R7
17 9706921
- 9706921 - HOSE CLAMP
- 12.7mm - 35mm
18 82012722
- 82012722 - HOSE CLAMP
- 19mm - 28mm
- Worm Gear
- Hose
- Serial Range: 1/2"-29/32"
19 9860006
- 9860006 - TUBE
- Assy.
- Incl. 17
- 18
- 484.6mm
20 87442037
- 87442037 - HYD TUBE
- 12.7 mm OD x 474.5
- 149.1 mm L
- Return
- Incl. 17
- 18
- 474.5mm
- Start Year: 05-APR-04
21 235671
- 235671 - SLEEVE
- 37 Degree
- 1/2" Tube
22 129428
- 129428 - TUBE NUT
- 37 Degree
- 3/4"-16
- Type B
23 176081
- 176081 - HYD CONNECTOR
- 3/4"-16
- 37 Degree x 1 1/16"-12
- O-Ring
- Incl. 20
24 167266
- 167266 - O-RING
- 0.116" Thk x 0.924" ID
- -912
- Cl 6
- 90 Duro
25 9806765
- 9806765 - HYDRAULIC VALVE
- Check
- 110
26 9840727
- 9840727 - 3 WAY CONNECTION
- Tee
- Run
- Special
- Incl. 20
27 86539484
- 86539484 - PIPE PLUG
- Sq Hd
- 1/8"-27
- NTPF
28 9800633
- 9800633 - FILTER
- Incl. 25
- 26
- 42
29 87014886
- 87014886 - FILTER
- Incl. 25
- 26
- 42
- LS140 On & ASN LMU004821
- LS140E On & ASN LMU004314
- LS150 On & ASN LMU024705
- LS150E On & ASN LMU00
30 9842392
- 9842392 - HYDRAULIC OIL FILTER
- Part of 9800633
- 87014886
31 8604802
- 8604802 - PRESSURE SWITCH
- Hydraulic Oil Filter Restrict
32 8604802
- 8604802 - PRESSURE SWITCH
- Part of 87014886
33 322894
- 322894 - 90 ELBOW
- 1-1/16" - 12 JIC x 1-1/16" - 12 ORB
- Incl. 20
34 86583004
- 86583004 - HYD TUBE
- 19.05 mm OD
- Incl. 32
- 33
- BSN
35 87050095
- 87050095 - HYD TUBE
- Incl. 32
- 33
- LS140 On & ASN LMU004821
- LS140E On & ASN LMU004314
- LS150 On & ASN LMU024705
- LS150E On & ASN LMU002492
36 164912
- 164912 - SLEEVE
- 37 Degree
- 3/4" Tube
37 86513085
- 86513085 - TUBE NUT
- 1-1/16"-12
- 37 Degree Fl
- Type B
38 219603
- 219603 - 90 ELBOW
- 1-1/16" - 12 JIC x 1-1/16" - 12
- 37 Degree Fem Sw
39 86552866
- 86552866 - OIL COOLER
- Oil
- Fittings On Opposite Sides
40 86510506
- 86510506 - TUBE
- 19.05 mm OD x 104.1
- 243.9 mm L
- Approx 337.2mm Long
- Incl. 32
- 33
41 87055202
- 87055202 - HYD TUBE
- 19.05 mm OD x 305.4
- 336 mm L
- To Cooler
- Incl. Ref. 32
- 33
42 164912
- 164912 - SLEEVE
- 37 Degree
- 3/4" Tube
43 86513085
- 86513085 - TUBE NUT
- 1-1/16"-12
- 37 Degree Fl
- Type B
44 144121
- 144121 - UNION
- 1-1/16" - 12 JIC x 1-1/16" - 12 JIC
45 86510505
- 86510505 - TUBE
- 19.05 mm OD
- Approx 943.9 mm Long
- Incl. 32
- 33
46 9706732
- 9706732 - CLAMP
- 19mm ID
- 8.7mm Bolt Hole
- P Type
47 86545825
- 86545825 - SELF-TAP SCREW
- Hex Wash Hd
- 5/16" x 5/8"
48 86504078
- 86504078 - PLATE
49 88206
- 88206 - BOLT
- Hex
- 3/8" - 16 x 1"
- Gr 5
50 88011
- 88011 - BOLT
- Hex
- 3/8" - 16 x 1 1/4"
- Gr 5
51 80702
- 80702 - WASHER
- 0.44" ID x 1" OD x 0.08" Thk
52 9628503
- 9628503 - NUT
- 3/8"-16
- G5
53 86534120
- 86534120 - FILTER HEAD
- Part of 9800633
54 87036104
- 87036104 - FILTER HEAD
- Part of 87014886
55 213404
- 213404 - SPACER
- 10.3mm ID x 38.1mm OD x 5.2mm OAL
56 523282
- 523282 - SERRATED NUT
- Flg
- USR
- 1/4"-20
57 9707580
- 9707580 - BOLT
- Hex
- 1/4" - 20 x 3/4"
- Gr 5
- Full Thd
58 257492
- 257492 - CLAMP
- 14.3mm
- Coat
- 10.3mm Bolt Hole
- P Type
