SPACER
1 6503451
- 6503451 - SPACER
2 6534111
- 6534111 - WASHER
- 5
3 6534154
- 6534154 - RING
- RETAINER
4 6597198
- 6597198 - PIN
- PIVOT SWING
5 6665618
- 6665618 - RING
- SNAP
6 6666549
- 6666549 - WASHER
7 6807956
- 6807956 - BUSHING
8 7135322
- 7135322 - PIN
- Do Not Use Ref. 13 on bottom side with this pin.
9 6807962
- 6807962 - WASHER
10 6807964
- 6807964 - PIN
- for boom swing cylinder
11 7135321
- 7135321 - PIN
- Do Not Use Ref. 13 on bottom side with this pin.
12 6810698
- 6810698 - FRAME
13 6808174
- 6808174 - WASHER
14 6808175
- 6808175 - RING
- RETAINER
- retaining
15 6808205
- 6808205 - PIN
- for boom cylinder
16 6808211
- 6808211 - BOLT
17 6808267
- 6808267 - PIN
- for boom swing cylinder
18 6808601
- 6808601 - BRACKET
19 6808984
- 6808984 - BRACKET
20 6809253
- 6809253 - SUPPORT
21 10H25
- 10H25 - FTG GREASE STRAIGHT
22 17EM120
- 17EM120 - WASHER
23 29CM1020
- 29CM1020 - SCREW HEX 10MMX20MM
24 29CM1235
- 29CM1235 - BOLT
25 51DM10
- 51DM10 - NUT HX THDLK PREAPPL
26 6815278
- 6815278 - BUSHING
- PRESS FIT
- Was 6810581
27 6810704
- 6810704 - RING
- SNAP
28 6811636
- 6811636 - SPACER
