Bobcat
/
331.0
/
VALVE SECTION 6677992

VALVE SECTION 6677992

VALVE SECTION 6677992

1 6677992

  • 6677992 - VALVE SECTION
  • boom swing - Ref. 2 - 15

2 73G414

  • 73G414 - CAPSCRW10
  • Was 6518610

3 948192

  • 948192 - CAP

4 6679106

  • 6679106 - END
  • SPOOL

5 6668963

  • 6668963 - SEAT
  • spring - yellow

6 6676360

  • 6676360 - SPRING

7 948016

  • 948016 - PLATE

8 6668972

  • 6668972 - SEAL
  • O-RING

9 948021

  • 948021 - SEAL
  • WIPER
  • wiper

10 6671684

  • 6671684 - BOLT

11 6665463

  • 6665463 - VALVE LOCK OUT ASSEMBLY
  • assy. - lockout

12 6665462

  • 6665462 - SPOOL

13 6665464

  • 6665464 - PIN
  • DOWEL
