PIPE 6682538 (2)

PIPE 6682538 (2)

PIPE 6682538 (2)

1 6682538

  • 6682538 - PIPE

2 7022765

  • 7022765 - BOLT
  • EYE
  • Was 7022765

3 3974095

  • 3974095 - GASKET
  • METAL
  • copper - Was 6680792

4 6675625

  • 6675625 - BOLT
  • EYE
  • eye joint - Was 6680566

5 7000642

  • 7000642 - WASHER
  • SEALING COPPER
  • consists of 2 gaskets attached by a tab - Was 6685962

6 6682539

  • 6682539 - PIPE
  • oil

7 6680570

  • 6680570 - GASKET

8 6652580

  • 6652580 - BOLT

9 6684884

  • 6684884 - PIPE

10 6685600

  • 6685600 - PIPE

11 6675618

  • 6675618 - CLAMP
  • hose

12 6685601

  • 6685601 - CLAMP
  • pipe

13 6680576

  • 6680576 - PIN
  • band
