PUMP, HYD 6682414
1 6682414
- 6682414 - PUMP
- HYD
- Ref. 2 - 49
2 6691458
- 6691458 - RING
- Was 6686754
3 6672231
- 6672231 - SEAL
- Was 6686751
4 6671787
- 6671787 - O-RING
5 6686757
- 6686757 - PLUG
- W/Ref. 5
6 6686752
- 6686752 - O-RING
7 6672228
- 6672228 - BEARING
- Was 6686749
8 6672224
- 6672224 - CRADLE ASSEMBLY
- Was 6686746
9 6686747
- 6686747 - SHAFT DRIVE
10 6686776
- 6686776 - PIPE
- includes fittings
11 6676393
- 6676393 - PIN
- Was 6686773
12 6676391
- 6676391 - CARRIER
- Was 6686769
13 6686771
- 6686771 - SCREW
- SOCKET
14 6686770
- 6686770 - O-RING
15 6679148
- 6679148 - SPRING
16 6686768
- 6686768 - VALVE
- does not include spring seat - Also Order 6679148 spring & 6679149 spring
17 6679149
- 6679149 - SPRING
18 6691344
- 6691344 - O-RING
19 6686775
- 6686775 - CAP
- INSULATION
20 6671783
- 6671783 - PLUG
- goes in the X port - Was 6686767
21 6672245
- 6672245 - LENS PLTE
- Was 6686761
22 6672220
- 6672220 - ASSY
- BLOCK
- Ref. 21 - 29 - Was 6686743
23 6688520
- 6688520 - CONTROL
- Ref. 21 - 39 - Was 6686744
24 6691449
- 6691449 - SHIM
- adjusting - Was 6686748
25 6672229
- 6672229 - BEARING
- Was 6686750
26 6672235
- 6672235 - DOWEL PIN
- Was 6686759
27 6686745
- 6686745 - PLATE
28 6671783
- 6671783 - PLUG
- goes in the X port - Was 6686767
29 6672255
- 6672255 - BOLT
- Was 6686766
30 6686695
- 6686695 - SEAL KIT
- Ref. 4
- 5
- 7
- 16
- 20
- 44 & Ref. 3
- 6
- 10
- 11 & 12
31 6686777
- 6686777 - FITTING
- Was 6688563
32 6686765
- 6686765 - O-RING
33 7001950
- 7001950 - CONTROL
- Use W/gasket - must replace gasket each time controller is removed
34 6691519
- 6691519 - GASKET
- one time use - must replace when controller is removed
35 6691491
- 6691491 - PLUG
- W/Ref. 56
36 6692558
- 6692558 - SCREW
