BOLT 6684836 (4)

BOLT 6684836 (4)

BOLT 6684836 (4)

1 6684836

  • 6684836 - BOLT
  • adjusting - W/Ref. 2

2 3974971

  • 3974971 - NUT

3 3974972

  • 3974972 - GASKET

4 6655223

  • 6655223 - CAP

5 6685526

  • 6685526 - PLATE
  • CONTROL
  • control assy. - Ref. 7-11
  • 16-19

6 6684838

  • 6684838 - GOVERNOR

7 6684839

  • 6684839 - LEVER

8 6685476

  • 6685476 - SEAL
  • oil

9 6598098

  • 6598098 - PIN
  • spring

10 6684823

  • 6684823 - SPRING

11 6684841

  • 6684841 - GASKET
  • Was 6684824

12 4CM620

  • 4CM620 - BOLT
  • Was 1CM620

13 6652764

  • 6652764 - STUD
  • Was 3974462B

14 6670533

  • 6670533 - NUT

15 7010195

  • 7010195 - BOLT
  • ADJUSTMENT

16 1DM6

  • 1DM6 - NUT
  • Was NSS
