U-JOINT 6598347

U-JOINT 6598347

U-JOINT 6598347

1 6598347

  • 6598347 - U-JOINT
  • Ref. 2-5 & 8 - full assembly

2 7359851

  • 7359851 - JOINT UNIVERSAL
  • Ref 2
  • 3
  • 5 & 8 - does not include Ref. 4

3 6598303

  • 6598303 - SPIDER

4 11H25

  • 11H25 - FITTING10

5 6598304

  • 6598304 - SPIDER

6 6562960

  • 6562960 - YOKE
  • POWER TRANSFER
  • W/Ref. 3 & 7

7 12F114

  • 12F114 - PLUG

8 94G524

  • 94G524 - BOLT 5

9 94G512

  • 94G512 - BOLTS 5

10 94G510

  • 94G510 - BOLTS 5

11 7106572

  • 7106572 - ADAPTER
  • SHAFT
  • Was 6558924

12 616783

  • 616783 - WASHER

13 18C616

  • 18C616 - BOLT 5
