751.0
/
LEVER 6707349 (2)

LEVER 6707349 (2)

LEVER 6707349 (2)

1 6707349

  • 6707349 - LEVER

2 6707367

  • 6707367 - GRIP

3 6702990

  • 6702990 - BUSHING
  • bronze sleeve

4 6707351

  • 6707351 - LEVER

5 6707352

  • 6707352 - LEVER

6 6631036

  • 6631036 - BALLJOINT

7 8D4

  • 8D4 - NUT

8 86D4

  • 86D4 - NUT

9 6666379

  • 6666379 - CABLE

10 4F4051

  • 4F4051 - PIN

11 6513495

  • 6513495 - PIN 5

12 2J4200

  • 2J4200 - CLEVIS

13 6592766

  • 6592766 - U-BOLT

14 83D5

  • 83D5 - LKNUT HEX FLG GR8

15 6706420

  • 6706420 - MOUNT
  • cable

16 6706421

  • 6706421 - MOUNT
  • cable

17 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

18 6702776

  • 6702776 - STEP

19 57D6

  • 57D6 - NUT HEX FLNG GR8

20 37C620

  • 37C620 - BOLT CARRIAGE
  • carriage

21 6706281

  • 6706281 - BELLCRANK
  • W/Ref. 26

22 58K014

  • 58K014 - O-RING 10

23 6702782

  • 6702782 - BRG SLEV.
  • bronze - Not in Kit

24 6655781

  • 6655781 - BEARING
  • THRUST
  • thrust

25 38C816

  • 38C816 - BOLT
  • shoulder

26 6563914

  • 6563914 - WASHER

27 38C610

  • 38C610 - SCREW SHOULDER
  • Was 6704285

28 85D4

  • 85D4 - NUT 5

29 6702774

  • 6702774 - LINK
  • TILT
  • tilt

30 38C606

  • 38C606 - BOLT
  • shoulder

31 6658682

  • 6658682 - BEARING
  • swivel

32 17C410

  • 17C410 - BOLT 10

33 6702773

  • 6702773 - LINK
  • LIFT
  • lift

34 6658930

  • 6658930 - BOOT

35 25G612

  • 25G612 - SCREW
  • socket hex head

36 6703724

  • 6703724 - DECAL
  • WARNING
  • operating

37 6703726

  • 6703726 - DECAL
  • WARNING
  • warning

38 6558309

  • 6558309 - CABLE BULK/FT
  • bulk - sold per foot - Also Order (2) of 6558310 sleeve

39 6558310

  • 6558310 - SLEEVE
  • wire rope

40 6708159

  • 6708159 - OHB
  • W/WIRE ROPE

41 6703725

  • 6703725 - DECAL
  • WARNING
  • warning

42 6641180

  • 6641180 - LOCK METRI PACK
  • Use W/ 2-pin connector

43 6640700

  • 6640700 - LOCK METRI PACK
  • 3-pin

44 6641179

  • 6641179 - CONNECTOR METRI PACK
  • 2-pin

45 6640699

  • 6640699 - CONNECTOR METRI PACK
  • 3-pin

46 6641178

  • 6641178 - CONNECTOR METRI PACK
  • 2-pin

47 6664599

  • 6664599 - CONNECTOR 3 PIN
  • 3-pin triangle

48 6664800

  • 6664800 - LOCK SECONDARY
  • 3-pin triangle

49 6641173

  • 6641173 - CONNECTOR
  • 6-pin

50 6641181

  • 6641181 - LOCK
  • 6-pin

51 6706568

  • 6706568 - KIT
  • HANDLE
  • MULTI-SWITCH - INCLUDES Ref. 48-50

52 6680447

  • 6680447 - DECAL
  • Was 6677370

53 6662257

  • 6662257 - PIN

54 6641176

  • 6641176 - SEAL

55 6640691

  • 6640691 - TERMINAL

56 6640690

  • 6640690 - PIN

57 6680412

  • 6680412 - HANDLE DLX LEFT
  • Multi-switch - L.H. - Was 6707976

58 6680413

  • 6680413 - HANDLE
  • SWITCH DLX
  • RH - multi switch - Was 6706340

59 6640690

  • 6640690 - PIN

60 6641176

  • 6641176 - SEAL

61 6706567

  • 6706567 - KIT
  • HANDLE DLX RH
  • MULTI-SWITCH - INCLUDES Ref. 44
  • 45
  • 46
  • 47 & 54

62 6666534

  • 6666534 - SEAL CABLE

63 6724043

  • 6724043 - INSTRUCTS "SALES ITEM ONLY"
