TANK, FUEL 6712882
1 6712882
- 6712882 - TANK
- FUEL
- See Note
2 7120881
- 7120881 - SCREEN
- FILLER
- Was 6569219
3 42H32
- 42H32 - HS CLAMP5
- Was 6513595
4 6710654
- 6710654 - HOSE
- Was 6709839
5 6701449
- 6701449 - FLR.TUBE
6 6632468
- 6632468 - FUEL CAP
- green
7 6661696
- 6661696 - CAP
- FUEL LOCKING
- locking - W/Ref. 15 Code PK510
8 42H10
- 42H10 - HOSECLAM5
9 6578278
- 6578278 - BUMP.PAD
- self adhesive one side
10 6666600
- 6666600 - FUELSCREN
11 6650239
- 6650239 - SCREEN
- FUEL PICKUP
12 6706517
- 6706517 - SCREW 10
13 6578172
- 6578172 - HOSE BULK
- sold per foot - 0.625" ID
14 6661213
- 6661213 - RING
- COMPRESSION
- For .25 ID Hose Ref. 11
15 7261455
- 7261455 - CLAMP
- For .50 ID Hose Ref. 11 - Was 6666602
16 6587458
- 6587458 - KEY CAP FUEL 2
- Code PK510
17 6553411
- 6553411 - BUSHING
- PRESS FIT 5
- 0.38" ID
18 6708817
- 6708817 - ELBOW
19 6598908
- 6598908 - ELBOW BARBED
- Was 6681462
20 42HS04
- 42HS04 - CLAMP HOSE TYPE M
- Was 6515575
21 6657734
- 6657734 - PUMP
- PRIMER HAND
- barbed fittings for 6
- 35 mm (.25") ID hose - barbed fittings for 6
- 35 mm (.25") ID hose
22 6658180
- 6658180 - PLUG
- BLEED
23 84G3712
- 84G3712 - SCREW THD ROLLING TT
24 6670873
- 6670873 - FILTERASY
- dual filter assy
25 6667352
- 6667352 - FILTER
- FUEL W/SEPARATOR 12
26 6670758
- 6670758 - FILTER
- WATER
- secondary fuel filter
27 72F1
- 72F1 - FITTING
28 6714478
- 6714478 - FILTER ASSEMBLY
- dual filter kit - includes filter assy 6670873 with 24" (610mm) of 6577822 bulk hose
29 6715183
- 6715183 - ELBOW 90 STRTHD TUBE
- W/Ref. 28 - Check boss face to determine correct replacement o-ring
30 17C512
- 17C512 - BOLT 5
31 99K5
- 99K5 - O-RING
- Tapered boss face
32 79K5
- 79K5 - O RING 10
- Flat boss face
33 30H36
- 30H36 - CLIP
34 17C612
- 17C612 - SCREW HEX CAP
35 61D6
- 61D6 - NUT HEX FINISHED GR5
36 7297323
- 7297323 - SENSOR
- FUEL
- fuel - W/Ref. 35 - (6717579 Gasket) - Was 7216453
37 6712909
- 6712909 - MOUNT
- BRACKET
- Was 6710447
38 6577822
- 6577822 - HOSE BULK
- sold per foot - .3125" ID
39 25K40102
- 25K40102 - O RING 10
- Was 79K000020B
40 6717579
- 6717579 - GASKET
41 6599645
- 6599645 - PLUG
- STEEL
- fuel drain
42 6708944
- 6708944 - HOSE - BULK/FT
- bulk-sold per foot - .50" I.D. (12
- 7 mm)
43 6578169
- 6578169 - HOSE BULK
- sold per foot - 0.19" ID
44 6553411
- 6553411 - BUSHING
- PRESS FIT 5
- 0.38" ID
45 6569752
- 6569752 - HOSE BULK/FT
- sold per foot - 0.25" ID
46 6667352
- 6667352 - FILTER
- FUEL W/SEPARATOR 12
47 72F1
- 72F1 - FITTING
48 7297009
- 7297009 - KIT FUEL SCREEN PICKUP TUBE
- W/Ref. 10
- 14
- 16
- 40
