SCREW 6588165 (3)
1 6588165
- 6588165 - SCREW
2 22E4
- 22E4 - WASHER
3 6587763
- 6587763 - BOOT
4 6592123
- 6592123 - RETAINER
5 6534630
- 6534630 - RESTRICTOR
- .134/.141
6 6666576
- 6666576 - SPOOL
- BOM
- lift - #1 or red - SEE NOTE
7 6666577
- 6666577 - SPOOL
- BOM
- lift - #2 or green - SEE NOTE
8 6666578
- 6666578 - SPOOL BOM
- lift - (3) black - SEE NOTE
9 6666579
- 6666579 - SPOOL
- TILT
- tilt - (1) red - SEE NOTE
10 6666580
- 6666580 - SPOOL
- TILT
- tilt - (2) green - SEE NOTE
11 6666581
- 6666581 - SPOOL
- TILT
- tilt - (3) black - SEE NOTE
12 7300937
- 7300937 - SPOOL AUX
- auxiliary - SEE NOTE - Was 6588074
13 6592115
- 6592115 - SEAT
14 6592117
- 6592117 - SPRING
- LOAD CHECK
15 79K8
- 79K8 - O RING 10
16 6592116
- 6592116 - NUT
- load check
17 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
18 6679961
- 6679961 - NUT
19 6586459
- 6586459 - SEAL KIT
- For 6653395 Valve
20 6717708
- 6717708 - COIL
- 14 VOLT
- 14 volt - W/Nut - Was 6665759
21 79K7
- 79K7 - O RING 10
22 6665758
- 6665758 - STEM
- W/ O-ring
23 6653395
- 6653395 - VALVE
- SOLENOID
- solenoid
24 58K017
- 58K017 - O-RING 10
25 6665569
- 6665569 - RING
- BACK-UP
- back-up
26 25K20016
- 25K20016 - O RING 10
27 6665570
- 6665570 - CLYD RING
- glide
28 6599161
- 6599161 - VALVE
- RELIEF
- port relief - 3400-3600 PSI - W/Ref. 23-25
29 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check - W/Ref. 23-25 - Was 6661345
30 79K10
- 79K10 - O RING 10
31 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
32 58K014
- 58K014 - O-RING 10
- back-up washer required
33 6677106
- 6677106 - O-RING
- back up washer NOT required
34 69G414
- 69G414 - BOLT
- .75" long - W/Ref. 43 (NLA/6538574 End Cap) - Was 6588164
35 6588982
- 6588982 - SCREW
- 1" long - Ref. 43 (Use W/6588981 End Cap)
36 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- W/.50" flange - Was 6587633
37 6592109
- 6592109 - ADAPTER
38 6592100
- 6592100 - COLLAR
39 6587580
- 6587580 - SPRING
40 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
41 799119
- 799119 - RING
42 6592098
- 6592098 - WASHER
43 6589226
- 6589226 - COVER
- END
- 0.63" flange
44 6531270
- 6531270 - SLEEVE
- DETENT
- lift
45 6587575
- 6587575 - ADAPTER
46 6592107
- 6592107 - SPRING
- DETENT 5
47 6592105
- 6592105 - BALL 5
48 6586918
- 6586918 - SCREW
- DETENT
49 6596807
- 6596807 - PLUG
- plastic - 0.46" long
50 54K20002
- 54K20002 - O'RING 10
51 19K5
- 19K5 - FITTING
- W/Ref. 45
52 6588981
- 6588981 - END CAP
- .625" thick
53 6592720
- 6592720 - PLUG
- W/Ref. 23-25
54 79K6
- 79K6 - O RING 10
55 58K124
- 58K124 - O RING 10
56 6537096
- 6537096 - WASHER
57 6530899
- 6530899 - SPRING
58 6577690
- 6577690 - TUBELINE
59 21K5
- 21K5 - TEE
- W/Ref. 45
60 6662920
- 6662920 - VALVE
- cold by-pass - Ref. 23 & 52-56 - 400 PSI
61 79K12
- 79K12 - O RING 10
62 6700524
- 6700524 - HOUSING VALVE
63 6515078
- 6515078 - POPPET
64 6565425
- 6565425 - SPRING
65 15K7
- 15K7 - FITTING
- W/Ref. 23
66 6538466
- 6538466 - BUSHING
67 6646372
- 6646372 - SEAL
- QUAD RING
- quad ring seal
68 6665089
- 6665089 - SEAL 5
- lip seal - Was 6659554
69 6662848
- 6662848 - CAP
- Use W/6587633 Bonnet
70 6588163
- 6588163 - SCREW
71 6661225
- 6661225 - VALVE
- RELIEF
- main relief - 3250-3350 PSI
72 6664373
- 6664373 - VALVE
- RELIEF
- optional port relief & anti-cav - W/Ref. 23 - 2500 PSI - use in tilt cylinder base end port
73 6660644
- 6660644 - CAP
74 6816250
- 6816250 - KIT
- SEAL
- - Ref. 2
- 4
- 41
- 58 & 60 - for one spool - Was 6803605
75 6632279
- 6632279 - KIT
- SEAL
- Ref. 17-20
76 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 23-25 - Was 6586461
77 6816715
- 6816715 - KIT
- SEAL
- - Ref. 4
- 13
- 16-20
- 23-25
- 41
- 45
- 46
- & 58 - Was 6596311
