KIT, ELECTRICAL CONTROLS 6712820

KIT, ELECTRICAL CONTROLS 6712820

KIT, ELECTRICAL CONTROLS 6712820

1 6712820

  • 6712820 - KIT
  • ELECTRICAL CONTROLS
  • controls - W/ handles - PWM - Ref. 2-31
  • 38 & 39 - SEE NOTE

2 6640690

  • 6640690 - PIN

3 6641176

  • 6641176 - SEAL

4 6640690

  • 6640690 - PIN
  • PWM

5 6641176

  • 6641176 - SEAL
  • PWM

6 6662257

  • 6662257 - PIN
  • PWM

7 6680457

  • 6680457 - HNDL/4 SWITCH PWM
  • R.H. - Also Order Ref. 7
  • 8
  • 38 & 39 - PWM - Was 6705924

8 6680413

  • 6680413 - HANDLE
  • SWITCH DLX
  • RH - multi switch - Also Order Ref. 4
  • 5
  • 7 & 8 - Was 6706340

9 6680412

  • 6680412 - HANDLE DLX LEFT
  • L.H. - Also Order Ref. 4
  • 5 & 9-11 - Was 6707976

10 6640690

  • 6640690 - PIN

11 6641176

  • 6641176 - SEAL

12 6662257

  • 6662257 - PIN

13 6640691

  • 6640691 - TERMINAL

14 6641180

  • 6641180 - LOCK METRI PACK
  • Use W/ 2-pin connector

15 6640700

  • 6640700 - LOCK METRI PACK
  • 3-pin

16 6641180

  • 6641180 - LOCK METRI PACK
  • Use W/ 2-pin connector - PWM

17 6640700

  • 6640700 - LOCK METRI PACK
  • 3-pin

18 6640699

  • 6640699 - CONNECTOR METRI PACK
  • 3-pin - PWM

19 6641179

  • 6641179 - CONNECTOR METRI PACK
  • 2-pin - PWM

20 6640699

  • 6640699 - CONNECTOR METRI PACK
  • 3-pin

21 6641179

  • 6641179 - CONNECTOR METRI PACK
  • 2-pin

22 6664036

  • 6664036 - NUT

23 6641181

  • 6641181 - LOCK
  • 6-pin

24 6641173

  • 6641173 - CONNECTOR
  • 6-pin

25 6641178

  • 6641178 - CONNECTOR METRI PACK
  • 2-pin

26 6664800

  • 6664800 - LOCK SECONDARY
  • 3-pin triangle

27 6664599

  • 6664599 - CONNECTOR 3 PIN
  • 3-pin triangle

28 6711621

  • 6711621 - MOUNT
  • Use W/Ref. 48

29 6706753

  • 6706753 - MOUNT
  • Use W/Ref. 12

30 6624289

  • 6624289 - STRAP
  • TIE
  • Was 6610510

31 6664035

  • 6664035 - CAP

32 45G508

  • 45G508 - BOLT

33 50D5

  • 50D5 - NUT

34 84G3712

  • 84G3712 - SCREW THD ROLLING TT

35 6706552

  • 6706552 - HARNESS
  • for grader

36 45G1212

  • 45G1212 - BOLT

37 50D12

  • 50D12 - NUT

38 6664040

  • 6664040 - PIN 5

39 6664041

  • 6664041 - PIN 10

40 6651975

  • 6651975 - SWITCH
  • RELAY MAGNETIC
  • relay - Use W/Ref. 12

41 6670312

  • 6670312 - SWITCH
  • MAGNETIC
  • relay - Use W/Ref. 48 - Was 6665005

42 6664388

  • 6664388 - DIODE
  • memory

43 6702650

  • 6702650 - MOUNT FUSE

44 6706446

  • 6706446 - HARNESS

45 6649028

  • 6649028 - CONNECTOR

46 6664181

  • 6664181 - CONNECTOR
  • Not in Kits

47 6664182

  • 6664182 - CONNECTOR
  • Not in Kits

48 6667569

  • 6667569 - CONNECTOR
  • RECEPTACLE
  • W/Ref. 50 - Also Order (14) of Ref. 22 - Was 6664039

49 6665001

  • 6665001 - CONNECTOR
  • ELECTRICAL
  • W/Ref. 50 - not in kits - Also Order (6) of Ref. 23 - Was 6664034

50 6706392

  • 6706392 - HARNESS
  • not in kits - connects old loader harness to new attachment harness - W/Ref. 30 & 31

51 6706391

  • 6706391 - HARNESS
  • not in kits - connects new loader harness to old attachment harness - W/Ref. 29 & 32

52 6664037

  • 6664037 - WASHER

53 6706568

  • 6706568 - KIT
  • HANDLE
  • handle - Ref. 4
  • 5 & 9-11 & 46

54 6706567

  • 6706567 - KIT
  • HANDLE DLX RH
  • handle - W/Ref. 4
  • 5
  • 7
  • 8 & 46

55 6706735

  • 6706735 - KIT
  • HANDLE DLX
  • handle - W/Ref. 7
  • 8 & 38-46 - PWM

56 6662246

  • 6662246 - CONNECTOR
  • 6-pin - PWM

57 6662252

  • 6662252 - LOCK
  • 6-pin - PWM

58 6709176

  • 6709176 - BRACKET

59 6709177

  • 6709177 - BRACKET

60 17C612

  • 17C612 - SCREW HEX CAP

61 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

62 30H46

  • 30H46 - CLIP

63 30H49

  • 30H49 - CLAMP

64 6722759

  • 6722759 - INSTRUCTIONS
  • FOR Ref. 3-36

65 6722758

  • 6722758 - INSTRUCTIONS
  • for electrical control kit

66 6724295

  • 6724295 - INSTRUCTIONS
  • for electrical control kit - W/ proportional auxiliaries

67 6724569

  • 6724569 - INSTRUCTIONS
  • for electrical control kit - W/ proportional auxiliaries

68 6710299

  • 6710299 - HARNESS
  • ATTACHMENT PWM

69 6710300

  • 6710300 - HARNESS

70 6669286

  • 6669286 - CLAMP
  • W/ saddles

71 6669201

  • 6669201 - MODULE
  • jumper harness - not in kit

72 6716799

  • 6716799 - KIT
  • AUX
  • dual function aux. - Ref. 53-57

73 6716844

  • 6716844 - HARNESS
  • jumper

74 6670312

  • 6670312 - SWITCH
  • MAGNETIC
  • relay

75 6716798

  • 6716798 - HARNESS
  • KP diverter

76 6624289

  • 6624289 - STRAP
  • TIE

77 6900601

  • 6900601 - INSTRUCTIONS
