SECTION 6511603

SECTION 6511603

SECTION 6511603

1 6511603

  • 6511603 - SECTION
  • valve - Ref. 2-30

2 58K23

  • 58K23 - O RING 10

3 58K26

  • 58K26 - O RING 10

4 898372

  • 898372 - ADAPTOR
  • clevis

5 6510751

  • 6510751 - PLATE
  • RETAINER

6 945225

  • 945225 - SEAL
  • quad ring

7 5C410

  • 5C410 - BOLT
  • W/Lock Washer

8 6518327

  • 6518327 - COLLAR

9 6519047

  • 6519047 - SPRING

10 6510771

  • 6510771 - COLLAR

11 6510772

  • 6510772 - SPACER

12 73G612

  • 73G612 - CAPSCREW

13 6510765

  • 6510765 - BONNET

14 6647692

  • 6647692 - SCREW
  • W/Lock Washer - Was 5C000416B

15 6655436

  • 6655436 - VALVE
  • RELIEF
  • relief - W/Ref. 2
  • 3 & 21-27 - Was 6518315

16 79K8

  • 79K8 - O RING 10

17 896265

  • 896265 - SHIM
  • .010

18 896264

  • 896264 - SHIM
  • .020

19 896263

  • 896263 - SHIM
  • .030

20 6660105

  • 6660105 - SEAL KIT
  • COMPLETE FOR 1 SECTION
