SEAT, OPERATOR SUSPENSION 6674019

SEAT, OPERATOR SUSPENSION 6674019

SEAT, OPERATOR SUSPENSION 6674019

1 6674019

  • 6674019 - SEAT
  • OPERATOR SUSPENSION
  • Ref. 2-28 - Was 6647432

2 6650226

  • 6650226 - CUSHION
  • SEAT VINYL
  • W/Ref. 3

3 6650231

  • 6650231 - 12 CLIP KIT

4 6650219

  • 6650219 - KNOB
  • Ref. 3 - W/Nut
  • Bushing

5 6650241

  • 6650241 - PUSH NUT

6 6650230

  • 6650230 - KIT
  • SEAT
  • W/Mounting Hardware

7 6650221

  • 6650221 - TL. LATCH
  • Ref. 8 - W/Mounting Hardware

8 6650229

  • 6650229 - SPRING

9 6650228

  • 6650228 - TRACK

10 6599779

  • 6599779 - TRACK
  • W/Mounting Hardware - Was 6650227

11 6650242

  • 6650242 - TIP

12 61D5

  • 61D5 - NUT HEX FINISHED GR5

13 6650222

  • 6650222 - SPRING

14 6650223

  • 6650223 - CABLE

15 6650243

  • 6650243 - BOOT

16 6650220

  • 6650220 - SHROUD
  • W/Mounting Hardware

17 6650224

  • 6650224 - SUPPORT
  • RH & LH Backrest

18 6650245

  • 6650245 - WASHER

19 6650247

  • 6650247 - WASHER

20 6650248

  • 6650248 - SPACER

21 17C510

  • 17C510 - BOLT

22 6650250

  • 6650250 - WASHER

23 6650251

  • 6650251 - CLIP

24 6668717

  • 6668717 - SCREW

25 6706966

  • 6706966 - SPRING
  • SEAT
  • Plate

26 6724017

  • 6724017 - INSTRUCTIONS
