WASHER, 5 6534111 (1)
1 6534111
- 6534111 - WASHER
- 5
2 6534154
- 6534154 - RING
- RETAINER
3 6597572
- 6597572 - BUMPER
4 6628341
- 6628341 - BUSHING
- PRESS FIT
- Use W/pin W/10 mm dia cross bolt retaining hole
5 7172745
- 7172745 - BUSHING
- WEAR
- Use W/pin W/ 12 mm dia cross bolt retaining hole
6 7176031
- 7176031 - LINK
7 7143009
- 7143009 - PIN
- PIVOT BOOM
8 7143561
- 7143561 - O-RING
- 3.23" (81
- 9 mm) ID
9 7143562
- 7143562 - O-RING
- 69
- 2 mm (2.73") ID
10 7176090
- 7176090 - PIN
- W/A
11 7180024
- 7180024 - ARM
- DIPPER W/A EXC
- standard arm - Also Order Ref. 4
- 7 (7143562 o-ring)
- 12
- 17
- & 22
12 7176092
- 7176092 - PIN
- W/A
13 7167301
- 7167301 - BUSHING
- WEAR
14 7176033
- 7176033 - LINK
15 10H25
- 10H25 - FTG GREASE STRAIGHT
16 26GM10020
- 26GM10020 - SCREW HEX THRDRLG
17 7180025
- 7180025 - ARM
- DIPPER W/A LONG EXC
- long arm - Also Order Ref. 4
- 7 (7143562 o-ring)
- 12
- 17
- & 22
18 6652915
- 6652915 - SEAL
- OIL
19 43DM10
- 43DM10 - NUT FLANGED HEX
20 7CM1090
- 7CM1090 - BOLT
- HEX SOCKET
21 6586391
- 6586391 - RETAINER
- weld-on
22 6669287
- 6669287 - SEAL
