Vibratory Plate Compactor
/
CONTROL,REMOYE IR54474911 (3)

CONTROL,REMOYE IR54474911 (3)

CONTROL,REMOYE IR54474911 (3)

1 IR54474911

  • IR54474911 - CONTROL
  • REMOYE
  • Ref. 9-17 & 24-28

2 IR54474929

  • IR54474929 - ARM
  • GOVERNOR

3 IR54474937

  • IR54474937 - ROD
  • GOVERNOR

4 IR54474945

  • IR54474945 - SPRING
  • GOVERNOR

5 IR54474952

  • IR54474952 - SPRING
  • RETURN

6 IR54474960

  • IR54474960 - LEVER
  • CONTROL

7 IR59244723

  • IR59244723 - SPRING
  • LEVER

8 IR54474978

  • IR54474978 - WASHER
  • CONTROL LEVER

9 IR54474986

  • IR54474986 - HOLDER
  • CABLE

10 IR54474994

  • IR54474994 - SPACER
  • CONTROL LEVER

11 IR54475017

  • IR54475017 - BASE
  • COMP. CONTROL

12 IR59244731

  • IR59244731 - SPRING
  • ADJUSTING

13 IR59244749

  • IR59244749 - SPRING
  • CABLE RETURN

14 IR54475025

  • IR54475025 - HOLDER
  • WIRE

15 IR54475033

  • IR54475033 - SCREW
  • RECESSED

16 IR59244756

  • IR59244756 - BOLT
  • FLANGE SUPERSEDED

17 IR59244772

  • IR59244772 - BOLT

18 IR54475041

  • IR54475041 - NUT
  • SELF LOCK

19 IR54475058

  • IR54475058 - SCREW
  • PAN

20 IR54475066

  • IR54475066 - CIRCLIP

21 IR54475074

  • IR54475074 - SCREW
  • PAN

22 IR54475090

  • IR54475090 - SCREW
  • PAN

23 IR59244780

  • IR59244780 - NUT
  • FLANGE SUPERSEDED
