CYLINDER HEAD IR13220983 (2)

CYLINDER HEAD IR13220983 (2)

CYLINDER HEAD IR13220983 (2)

1 IR13220983

  • IR13220983 - CYLINDER HEAD
  • W/Ref. 2-4

2 IR59242925

  • IR59242925 - GUIDE
  • VALVE

3 IR54473913

  • IR54473913 - GUIDE
  • VALVE

4 IR59242933

  • IR59242933 - GUIDE
  • VALVE

5 IR59242941

  • IR59242941 - CLIP

6 IR59242958

  • IR59242958 - GASKET
  • HEAD

7 IR13220991

  • IR13220991 - HEAD GASKET

8 IR54474028

  • IR54474028 - GASKET
  • CYLINDER HEAD

9 IR59242974

  • IR59242974 - PACKING

10 IR13221007

  • IR13221007 - BREATHER TUBE

11 IR59242982

  • IR59242982 - TUBE
  • BREATHER

12 IR59242990

  • IR59242990 - BOLT
  • FLANGE

13 IR54474036

  • IR54474036 - FLANGE BOLT
  • 6X13

14 IR54474044

  • IR54474044 - BOLT STUD
  • 6X109

15 IR59243212

  • IR59243212 - BOLT
  • STUD

16 IR59243220

  • IR59243220 - PIN
  • DOWEL

17 IR13221015

  • IR13221015 - TUBE CLIP

18 IR59243238

  • IR59243238 - BOLT
  • FLANGE

19 IR54474135

  • IR54474135 - SPARK PLUG

20 IR54474093

  • IR54474093 - SPARK PLUG

21 IR54474085

  • IR54474085 - SPARK PLUG
