(140SR-3) - ACERA CRAWLER EXCAVATOR - ASN YH07-09001 (6/12-12/13)
/
WASHER ZW16H16000

WASHER ZW16H16000

WASHER ZW16H16000

1 ZW16H16000

  • ZW16H16000 - WASHER

2 ZS18C16040

  • ZS18C16040 - SCREW
  • Hex
  • M16 x 40mm
  • Cap

3 YY52S00034F1

  • YY52S00034F1 - LEVEL GAUGE
  • Sensor

4 ZW26X05000

  • ZW26X05000 - LOCK WASHER
  • Lock

5 ZS31C05012

  • ZS31C05012 - BOLT
  • Phillips Drive
  • Pan HD
  • M5 x 12mm
  • Machine

6 YY20P01118P1

  • YY20P01118P1 - INSULATION

7 ZS18C16060

  • ZS18C16060 - SCREW
  • Hex
  • M16 x 60mm
  • Cap

8 YN25V00001P1

  • YN25V00001P1 - VALVE
  • Stop

9 YY20P01243P1

  • YY20P01243P1 - PLATE

10 ZM73C12020

  • ZM73C12020 - BOLT
  • M12x20mm - Course Thread
  • Sems

11 YY20P01254P1

  • YY20P01254P1 - INSULATION

12 YY20P01139P1

  • YY20P01139P1 - SHIM
  • (1.0)

13 YY20P01196P1

  • YY20P01196P1 - INSULATION

14 YY20P00079F1

  • YY20P00079F1 - FUEL TANK
  • ASSY.
  • Incl 15 - 19

15 YN20P01034P2

  • YN20P01034P2 - CAP
  • Locking Fuel Tank Filler

16 YN50V00029P1

  • YN50V00029P1 - FILTER STRAINER

17 YY20P01215P1

  • YY20P01215P1 - FLANGE

18 ZM73C10020

  • ZM73C10020 - BOLT
  • M10x20mm - Course Thread
  • Sems

19 ZD11G16000

  • ZD11G16000 - O-RING
  • 5.7mm Thk x 159.3mm ID
  • 70 Duro
