(140SR-3) - ACERA CRAWLER EXCAVATOR - ASN YH07-09001 (6/12-12/13)
/
WIRE HARNESS YY13E01359P2

WIRE HARNESS YY13E01359P2

WIRE HARNESS YY13E01359P2

1 YY13E01359P2

  • YY13E01359P2 - WIRE HARNESS
  • Upper

2 LE73E00001S001

  • LE73E00001S001 - FUSE BOX
  • Incl 1-2 - 1-4

3 YY73S00003P1

  • YY73S00003P1 - FUSE
  • 80 Amp
  • Grid/Air Intake Heater

4 YY73S00004P1

  • YY73S00004P1 - FUSE
  • 30 Amp

5 YN13E01322P1

  • YN13E01322P1 - CAP

6 YY13E01342P1

  • YY13E01342P1 - WIRE HARNESS
  • ECU

7 YY13E01265P1

  • YY13E01265P1 - CABLE
  • Battery Relay

8 YY13E01266P1

  • YY13E01266P1 - CABLE
  • Battery

9 YY13E01267P1

  • YY13E01267P1 - CABLE
  • Battery Earth

10 LE13E01006P1

  • LE13E01006P1 - HARNESS
  • 100mm Long (3-15/16 in)

11 YN13E01375P1

  • YN13E01375P1 - CLIP
  • M8 x 8.20mm Shank

12 PY01P01043D3

  • PY01P01043D3 - CABLE TIE
  • 188mm L

13 PY01P01043D8

  • PY01P01043D8 - CABLE TIE
  • 102mm L

14 EW02E01015D9

  • EW02E01015D9 - CLIP
  • 20mm ID
  • P Type

15 EW02E01015DA

  • EW02E01015DA - CLIP

16 EW02E01015DD

  • EW02E01015DD - CLIP

17 EZ03E01036P1

  • EZ03E01036P1 - CLIP

18 ZM73C08020

  • ZM73C08020 - BOLT
  • M8x20mm - Course Thread
  • Sems
