New Holland Construction
/
(575E) - TRACTOR LOADER BACKHOE (1/96-)
/
SOFT TRIM 85801640

SOFT TRIM 85801640

SOFT TRIM 85801640

1 85801640

  • 85801640 - SOFT TRIM

2 85805298

  • 85805298 - SOFT TRIM

3 79089592

  • 79089592 - WASHER
  • 6mm ID x 24mm OD x 5mm Thk

4 79105220

  • 79105220 - SCREW
  • Phillips Drive
  • Oval HD
  • M6 x 20mm

5 13311217

  • 13311217 - SCREW
  • Pozidriv Oval Hd
  • Csk
  • M5 x 20mm
  • Cl 5.8
  • Full Thd

6 85801643

  • 85801643 - SOFT TRIM

7 85801991

  • 85801991 - WASHER
  • 6.3mm OD x 18mm ID x 4mm Thk

8 14084814

  • 14084814 - FLANGE NUT
  • M8 x 1.25
  • Flg

9 5162852

  • 5162852 - RIVET
  • 7.3mm OD x 12mm L

10 15627011

  • 15627011 - RIVET
  • Flat
  • M6 OD x 15.5mm L

11 85801953

  • 85801953 - RIVET
  • M6

12 85805325

  • 85805325 - SOFT TRIM

13 85805347

  • 85805347 - THREADED BUSHING
  • M6 x 9.7mm OD x 20mm L

14 12638104

  • 12638104 - WASHER
  • 5.2mm ID x 14mm OD x 1mm Thk

15 14644790

  • 14644790 - RIVET

16 85804750

  • 85804750 - THREADED BUSHING
  • M5 x 9.7mm OD x 20mm L
