New Holland Construction
/
(575E) - TRACTOR LOADER BACKHOE (1/96-)
/
SUPPORT 85801031

SUPPORT 85801031

SUPPORT 85801031

1 85801031

  • 85801031 - SUPPORT

2 83910645

  • 83910645 - BUSHING
  • 70.35mm ID x 80.18mm OD x 32mm L

3 10520431

  • 10520431 - WASHER
  • 21mm ID x 35mm OD x 4mm Thk

4 12575121

  • 12575121 - NUT
  • M20 x 1.5
  • Cl 10

5 15988931

  • 15988931 - BOLT
  • Hex
  • M20 x 1.5 x 90mm
  • Cl 10.9

6 80710

  • 80710 - LUBE NIPPLE
  • 1/8” – 27 Dryseal PTF

7 85801153

  • 85801153 - SHIM
  • 1mm Thk

8 85803039

  • 85803039 - SHIM
  • 2mm Thk

9 85800300

  • 85800300 - CYLINDER

10 85800355

  • 85800355 - HYDRAULIC CYLINDER

11 87315529R

  • 87315529R - REMAN-HYD CYLINDER

12 87315529C

  • 87315529C - CORE-HYD CYLINDER

13 85800965

  • 85800965 - REDUCER
  • 16.9mm OD x 10.15mm L
