New Holland Construction
/
(B110B) - BACKHOE LOADER - TIER 3 (11/10-)
/
SCREW,M8 x 16mm

SCREW,M8 x 16mm

SCREW,M8 x 16mm

1 83984666

  • 83984666 - SCREW
  • M8 x 16mm

2 13838071

  • 13838071 - BOLT
  • Hex
  • M8 x 20mm

3 87613060

  • 87613060 - BACKREST

4 87613073

  • 87613073 - BACKREST

5 87613074

  • 87613074 - SEAT

6 85817481

  • 85817481 - HOLDER

7 82034863

  • 82034863 - SCREW
  • M4 x 8mm

8 47335213

  • 47335213 - BUSHING

9 85817485

  • 85817485 - SEAT BACK

10 85817453

  • 85817453 - ARMREST

11 85828196

  • 85828196 - ARMREST

12 85827918

  • 85827918 - ARMREST

13 82034881

  • 82034881 - WASHER
  • 8.4mm ID

14 85817459

  • 85817459 - NUT

15 13838071

  • 13838071 - BOLT
  • Hex
  • M8 x 20mm
