(B110C) - BACKHOE LOADER - TIER 4B (2/15-)
/
THREADED ROD,M8 x 310.6mm L

THREADED ROD,M8 x 310.6mm L

THREADED ROD,M8 x 310.6mm L

1 84166079

  • 84166079 - THREADED ROD
  • M8 x 310.6mm L

2 84166077

  • 84166077 - THREADED ROD
  • M8 x 319.9mm L

3 16102311

  • 16102311 - THIN NUT
  • Thin
  • M8 x 1.25
  • Cl 04

4 85804375

  • 85804375 - BALL JOINT
  • M8

5 87597953

  • 87597953 - NUT
  • M8
  • 1.25 Pitch
  • 10.6mm High
  • Cl 8
  • ZND

6 84166078

  • 84166078 - THREADED ROD
  • M8 x 10.3.4mm L

7 84166076

  • 84166076 - THREADED ROD
  • M8 x 112.8mm L

8 D149287

  • D149287 - PIN
  • 7.9mm OD x 26.72mm L

9 432-612

  • 432-612 - COTTER PIN
  • 3/32" x 3/4"

10 85805616

  • 85805616 - PIN
  • 6.35mm OD x 25.4mm L

11 85805690

  • 85805690 - LEVER
