(B90B) - BACKHOE LOADER TIER 3 (2008)
/
PLUG 85825254 (3)

PLUG 85825254 (3)

PLUG 85825254 (3)

1 85825254

  • 85825254 - PLUG

2 10615274

  • 10615274 - LOCK WASHER
  • Ext Tooth
  • M4

3 86625075

  • 86625075 - NUT
  • M4 x 0.7
  • Cl 8

4 85825129

  • 85825129 - ISOLATOR

5 87689317

  • 87689317 - HORN

6 79111978

  • 79111978 - PLUG
  • 23mm OD

7 10398980

  • 10398980 - GROMMET
  • 36mm ID x 46mm GRV ø x 56mm OD x 15mm Thk

8 5112712

  • 5112712 - COLLAR
  • M4.8 x 283

9 85821326

  • 85821326 - SUPPORT

10 16043121

  • 16043121 - SCREW
  • Hex
  • M8 x 1.25 x 14mm
  • Cl 8.8
  • Full Thd

11 85805383

  • 85805383 - CABLE TIE

12 87552128

  • 87552128 - ELECTRIC CABLE

13 85819193

  • 85819193 - WIRE HARNESS

14 85802310

  • 85802310 - PLUG
  • Black

15 85808460

  • 85808460 - PLUG

16 10902624

  • 10902624 - SCREW
  • Hex
  • M6 x 25mm
  • Cl 8.8
  • Full Thd

17 11193274

  • 11193274 - BELLEVILLE WASHER
  • M6 Bolt Size x 15mm OD x 1.2mm Thk

18 10398680

  • 10398680 - GROMMET
  • 25mm ID x 33mm GRV ø x 42mm OD x 15mm Thk

19 11193879

  • 11193879 - BELLEVILLE WASHER
  • M8 Bolt Size x 16mm OD x 1.4mm Thk

20 85825136

  • 85825136 - COVER

21 13272214

  • 13272214 - SCREW
  • Pozidriv Pan Hd
  • M4 x 16mm
  • Cl 5.8
  • Full Thd

22 87409315

  • 87409315 - KIT

23 85819195

  • 85819195 - WIRE HARNESS
