(B90B) - BACKHOE LOADER TIER 3 (2008)
/
TEMPERATURE SENDER 47048895 (2)

TEMPERATURE SENDER 47048895 (2)

TEMPERATURE SENDER 47048895 (2)

1 47048895

  • 47048895 - TEMPERATURE SENDER

2 16104111

  • 16104111 - NUT
  • Prevailing Torque
  • M8
  • 1.25 Pitch
  • 10.6mm High
  • Cl 08
  • ZND

3 12647121

  • 12647121 - WASHER
  • 8.15mm ID x 20mm OD x 3mm Thk

4 85820156

  • 85820156 - ADAPTER
  • 1/8" - 28 x 9/16" - 18 ORB

5 85817672

  • 85817672 - PRESSURE SWITCH

6 87405018

  • 87405018 - GROUND STRAP

7 87410268

  • 87410268 - GROUND STRAP

8 87407206

  • 87407206 - GROUND STRAP

9 47048993

  • 47048993 - LOCK WASHER
  • 10mm ID

10 47049010

  • 47049010 - BOLT
  • Hvy Hex
  • M10 x 20mm
  • Cl 8.8

11 47049031

  • 47049031 - NUT
  • M10 x 1.5
  • Cl 10

12 85826964

  • 85826964 - HYD CONNECTOR

13 87492241

  • 87492241 - FITTING
