KIT 47630072
1 47630072
- 47630072 - KIT
- Heavy Duty Hoods and Covers
- Incl 2 - 69
2 47630074
- 47630074 - INSTRUCTION
- Sheet
3 47671572
- 47671572 - PANEL
- Rear Deck
4 47574583
- 47574583 - SCREEN
- Tilt Hood
5 47503835
- 47503835 - PLATE
- Double
6 65319
- 65319 - WASHER
- 13.1mm ID x 25.4mm OD x 3.68mm Thk
7 87035448
- 87035448 - SPACER
- 8.48mm ID x 12.7mm OD x 12.7mm L
8 9671714
- 9671714 - FLANGE BOLT
- Hex
- M8 x 1.25 x 25mm
- Cl 8.8
9 9804277
- 9804277 - FLANGE NUT
- Hex
- M8 x 1.25
- Cl 8
10 9804258
- 9804258 - BOLT
- Hex
- M8 x 1.25 x 20mm
- Cl 8.8
11 86619801
- 86619801 - FLANGE NUT
- M8 x 1.25
- Cl 8
12 189609A1
- 189609A1 - BALL STUD
- M8 x 1.25
13 86629542
- 86629542 - NUT
- M8 x 1.25
- Cl 8.8
14 47670334
- 47670334 - ANGLE
- RH
- Cover Mounting
15 87030529
- 87030529 - SELF-TAP SCREW
- HWH
- 3/8" - 16 x 7/8"
16 87016586
- 87016586 - SPRING NUT
- Multi-Thd
- M8 x 1.25
17 47670330
- 47670330 - ANGLE
- LH
- Cover Mounting
18 47675202
- 47675202 - PANEL
- RH
- Cover
- Standard Flow
19 47675204
- 47675204 - PANEL
- RH
- Cover
- High Flow
20 47675206
- 47675206 - PANEL
- LH
- Cover
21 406256A1
- 406256A1 - HANDLE
- Rear Hood
22 86511827
- 86511827 - SCREW
- Phillips Drive
- Pan HD
- M5 x 20mm
- Cl 4.8
23 86625264
- 86625264 - LOCK WASHER
- Ext Tooth
- M5
24 86639241
- 86639241 - NUT
- Prev Torque
- M5 x 0.8
- Cl 8
25 47520292
- 47520292 - ANGLE
- Hood Lock Tab
26 84285339
- 84285339 - SELF-TAP SCREW
- Hex
- M8 x 1.25 x 15mm
27 84600804
- 84600804 - REINFORCEMENT
- Tilt Hood
28 84600802
- 84600802 - REINFORCEMENT
- Tilt Hood
29 47521161
- 47521161 - REINFORCEMENT
- Tilt Hood
30 47521067
- 47521067 - REINFORCEMENT
- Tilt Hood
31 87028323
- 87028323 - HEX SOC SCREW
- Btn Head
- M8 x 1.25 x 25mm
- Cl 8.8
32 84541176
- 84541176 - BRACKET
- 184.3mm L
33 87016557
- 87016557 - SELF-TAP SCREW
- Hex
- M8 x 1.25 x 25mm
34 87702286
- 87702286 - TRIM
- Bulk
- 1/8" x 30480mm L
- 250mm L
- Edge
35 47637107
- 47637107 - ROD
- 6.4mm OD
- Latch Pull
36 380751A1
- 380751A1 - NUT
- 6.35mm ID
- Push Cap
37 47365482
- 47365482 - FOAM INSULATION
- RH
- Fender Filler
38 47365484
- 47365484 - FOAM INSULATION
- LH
- Fender Filler
39 47365894
- 47365894 - SEAL
- 3050mm L
40 84338534
- 84338534 - SEAL
- Bulk 30.48 m
- 2375mm L
41 84598220
- 84598220 - FOAM INSULATION
- 130mm L
- LH
- Hood
42 84598643
- 84598643 - FOAM INSULATION
- 95mm L
- RH
- Hood
43 47383241
- 47383241 - FOAM INSULATION
- 30480mm L
- 300mm L
44 47377967
- 47377967 - FOAM INSULATION
- LH
45 47377968
- 47377968 - FOAM INSULATION
- RH
46 84602176
- 84602176 - SEAL
- 890mm L
47 84494851
- 84494851 - FOAM INSULATION
- LH
48 84494871
- 84494871 - FOAM INSULATION
- RH
49 47357144
- 47357144 - FOAM INSULATION
- 70mm L x 50.8mm W x 50.8mm H
- Deck
50 9804260
- 9804260 - BOLT
- Hex
- M8 x 1.25 x 30mm
- Full Thd
- Cl 8.8
51 47432047
- 47432047 - PLATE
- 173.5mm L
- Exhaust Stack
52 47461845
- 47461845 - PLATE
- 173.5mm L
- Exhaust Stack
53 87343550
- 87343550 - FLANGE BOLT
- Hex
- M12 x 25mm
54 87533547
- 87533547 - NUT
- Prev Torque
- M12
- 1.75mm Pitch
- Cl 10
55 291186
- 291186 - PROTECTION STRIP
- 9.9mm W
- 0.72"
- Edge Channel
56 47634779
- 47634779 - ANGLE
- Door Top
57 47635985
- 47635985 - ANGLE
- Light Bar Bracket
58 86511841
- 86511841 - BOLT
- Flng
- M8 x 1.25 x 16mm
- Full Thd
- Cl 8.8
59 86505868
- 86505868 - SERRATED NUT
- Hex
- M8 x 1.25
- Cl 8
60 47732028
- 47732028 - COVER
- Rear Door
61 47534064
- 47534064 - LIGHT ASSY.
- 12V
- 25W
- Turn/SMV
62 47537904
- 47537904 - LIGHT ASSY.
- 12V
- 10W
- Turn/SMV
63 86511189
- 86511189 - WASHER
- 0.16" ID x 0.38" OD x 0.05" Thk
64 86508812
- 86508812 - NUT
- M3
- Cl 8
65 86511481
- 86511481 - FLANGE BOLT
- Hex
- M8 x 1.25 x 50mm
- Cl 8.8
66 412250
- 412250 - NUT
- M8 x 1.25
- Cl 8
67 87668737
- 87668737 - CABLE TIE
- 203.2mm L
- Nylon
- Nylon
68 47541193
- 47541193 - WIRE HARNESS
- Rear Road Jumper
69 263117
- 263117 - CABLE TIE
- 292.1mm L
- Nylon
- Black
- Nylon
