VALVE 6537937
1 6537937
- 6537937 - VALVE
- Ref. 2-10 - also order 6 of Ref. 28 - Was 6592469
2 6588165
- 6588165 - SCREW
- Was 73G000410B
3 22E4
- 22E4 - WASHER
4 6592123
- 6592123 - RETAINER
5 6592119
- 6592119 - SPOOL
- Was NSS
6 6538466
- 6538466 - BUSHING
- With P/N 6538466 stamped on top
7 6592103
- 6592103 - BUSHING
- See Serviceletter 5 Jan. 87
8 6646372
- 6646372 - SEAL
- QUAD RING
- quad ring seal
9 6665089
- 6665089 - SEAL 5
- lip seal - Was 6659554
10 24K7
- 24K7 - PLUG
- W/Ref. 22
11 6592115
- 6592115 - SEAT
12 6592117
- 6592117 - SPRING
- LOAD CHECK
13 79K8
- 79K8 - O RING 10
14 6592116
- 6592116 - NUT
- load check
15 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
16 6592720
- 6592720 - PLUG
- W/Ref. 2-24
17 79K10
- 79K10 - O RING 10
18 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
19 6677106
- 6677106 - O-RING
- Back-up Washer Not Required
20 58K014
- 58K014 - O-RING 10
- back-up washer required - Was 25K20016
21 6588164
- 6588164 - SCREW
- Was 73G000412B
22 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- W/.50" flange - Was 6587633
23 6592109
- 6592109 - ADAPTER
24 6592100
- 6592100 - COLLAR
25 6587580
- 6587580 - SPRING
- Was 6592106
26 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
27 6587763
- 6587763 - BOOT
- See note
28 6662848
- 6662848 - CAP
- Use with 6587633 bonnet
29 6809425
- 6809425 - SEAL KIT
- Ref. 14 & 22-24 - Was 6586461
30 6661328
- 6661328 - SEAL KIT
- Ref. 16-19 - Was 6592474
31 6816250
- 6816250 - KIT
- SEAL
- - Ref. 9
- 14
- 16-19
- 22
- 25 & 33 - Was 6586464
32 6816250
- 6816250 - KIT
- SEAL
- - Ref. 9
- 25 & 33 - For One Spool - Was 6661315
