PUMP 6584076 (1)

PUMP 6584076 (1)

PUMP 6584076 (1)

1 6584076

  • 6584076 - PUMP
  • New

2 6513631

  • 6513631 - BOLT

3 6512939

  • 6512939 - COVER

4 6512940

  • 6512940 - SHIM KIT

5 6512938

  • 6512938 - SPACER

6 232539

  • 232539 - BEARING

7 4E6

  • 4E6 - WASHER

8 93G624

  • 93G624 - SCREW

9 6512949

  • 6512949 - O-RING
  • Was NSS

10 6513093

  • 6513093 - BEARING

11 6598478

  • 6598478 - PLATE
  • WEAR

12 6512948

  • 6512948 - KIT
  • BEARING
  • Spacer - Inlcudes one of each of the following

13 6674240

  • 6674240 - SPACER
  • .137"

14 6674241

  • 6674241 - SPACER
  • .139"

15 6674242

  • 6674242 - SPACER
  • .142"

16 6674244

  • 6674244 - SPACER
  • .148" - Was 6674344

17 6674245

  • 6674245 - SPACER
  • .151" - Was 6674345

18 6674246

  • 6674246 - SPACER
  • .154"

19 6674247

  • 6674247 - SPACER
  • .157"

20 6674248

  • 6674248 - SPACER
  • .160"

21 6674249

  • 6674249 - SPACER
  • .163"

22 6674250

  • 6674250 - SPACER
  • .166"

23 6674251

  • 6674251 - SPACER
  • .169"

24 6512932

  • 6512932 - SHAFT

25 5J806

  • 5J806 - KEY

26 6512929

  • 6512929 - YOKE

27 6513091

  • 6513091 - BEARING

28 6512941

  • 6512941 - GASKET

29 17C820

  • 17C820 - BOLT 5

30 616791

  • 616791 - WASHER

31 6513094

  • 6513094 - COVER
  • SEAL BEARING

32 6598902

  • 6598902 - PLUG

33 6598825

  • 6598825 - SHAFT

34 79K12

  • 79K12 - O RING 10

35 6512944

  • 6512944 - SPRING

36 6512946

  • 6512946 - SPRING

37 16F4

  • 16F4 - PLUG

38 6513089

  • 6513089 - PIN

39 6513092

  • 6513092 - PIN

40 507695

  • 507695 - SNAP RING

41 6513090

  • 6513090 - SEAL
  • SHAFT

42 6519654

  • 6519654 - KEY

43 6512942

  • 6512942 - SHAFT
  • DRIVE HYD

44 6512933

  • 6512933 - COUPLER

45 6598822

  • 6598822 - PUMP
  • vane

46 6598826

  • 6598826 - SEAL KIT
  • Ref. 5
  • 10
  • 19
  • 23
  • 26 & seals in vane pump
