Bobcat
/
319.0
/
VALVE

VALVE

VALVE

1 6979436

  • 6979436 - VALVE
  • W/Ref. 2-18

2 6693130

  • 6693130 - KIT
  • W/Ref. 3-7

3 6680092

  • 6680092 - VALVE
  • LOCK LOAD

4 6680066

  • 6680066 - KIT
  • SEAL
  • between sections - W/Ref. 6-7

5 6688427

  • 6688427 - KIT
  • W/Ref. 9-14

6 6682248

  • 6682248 - SCREW

7 7015360

  • 7015360 - CAP

8 7015361

  • 7015361 - BUSHING

9 7015362

  • 7015362 - SPRING

10 7015363

  • 7015363 - BUSHING

11 6680057

  • 6680057 - PLUG ASSEMBLY

12 6693139

  • 6693139 - GF/SDS100-SAE6 INLET JOINT

13 6693125

  • 6693125 - I124/SDS100 319 SLEW SPOOL

14 6679444

  • 6679444 - SEAL KIT
