Bobcat
/
442
/
BRACKET 7013460

BRACKET 7013460

BRACKET 7013460

1 7013460

  • 7013460 - BRACKET
  • W/Ref. 2-16

2 6513820

  • 6513820 - WASHER
  • Was 7013356

3 7028293

  • 7028293 - RING
  • SEALING
  • Was 6668108

4 7013464

  • 7013464 - GASKET

5 7013502

  • 7013502 - CONNECTOR HOSE

6 7013352

  • 7013352 - RING SEALING

7 7013368

  • 7013368 - BOLT HEXAGON

8 7013564

  • 7013564 - PUMP COOLANT

9 6681179

  • 6681179 - PLUG
  • Was 7013361

10 7013503

  • 7013503 - FITTING HOSE

11 7013558

  • 7013558 - SLEEVE GUIDE

12 7013461

  • 7013461 - MANIFOLD

13 7013405

  • 7013405 - BOLT HEXAGON

14 7013462

  • 7013462 - MANIFOLD
  • W/Ref. 17-18

15 7013465

  • 7013465 - GASKET

16 7013409

  • 7013409 - BOLT HEXAGON

17 6672939

  • 6672939 - O-RING
  • Was 7013350

18 6672938

  • 6672938 - PLUG
  • Was 7013364

19 5411664240

  • 5411664240 - COVER

20 5411666065

  • 5411666065 - O-RING
  • Was 5411664241

21 5411657379

  • 5411657379 - BOLT

22 5411664421

  • 5411664421 - THERMOSTAT

23 7013454

  • 7013454 - BRACKET

24 7013411

  • 7013411 - BOLT HEXAGON

25 7013566

  • 7013566 - CLAMP PIPE

26 7013455

  • 7013455 - TUBELINE COOLING WATER
  • W/Ref. 27-28

27 7013381

  • 7013381 - HOSE

28 7013382

  • 7013382 - CLAMP SPRING BAND

29 7013332

  • 7013332 - LUBRICANT

30 7013456

  • 7013456 - TUBELINE COOLING WATER
  • W/Ref. 27-28

31 5411663897

  • 5411663897 - TEMP. TRANSMITTER

32 7013561

  • 7013561 - MANIFOLD

33 7013562

  • 7013562 - GASKET

34 7013401

  • 7013401 - BOLT HEXAGON

35 7011159

  • 7011159 - SEAL

36 7011160

  • 7011160 - SEAL

37 7013378

  • 7013378 - BOLT HEXAGON

38 7011161

  • 7011161 - O-RING
