SUCTION PIPE 6688306 (2)

SUCTION PIPE 6688306 (2)

SUCTION PIPE 6688306 (2)

1 6688306

  • 6688306 - SUCTION PIPE

2 6688160

  • 6688160 - RUBBER SLEEVE

3 6670315

  • 6670315 - GASKET

4 6666419

  • 6666419 - CLAMP

5 6688184

  • 6688184 - BOLT

6 6688244

  • 6688244 - EXHAUST MANIFOLD

7 6666472

  • 6666472 - GASKET

8 6673171

  • 6673171 - BOLT

9 6672947

  • 6672947 - STUD
  • Was 6672947

10 6666473

  • 6666473 - GASKET

11 6672948

  • 6672948 - NUT

12 6668888

  • 6668888 - WASHER

13 6688241

  • 6688241 - HOSE

14 6672939

  • 6672939 - O-RING
  • Was 2FM10135

15 6687841

  • 6687841 - BOLT

16 6681423

  • 6681423 - BRACKET

17 6681421

  • 6681421 - CLAMP
  • HOSE

18 6511720

  • 6511720 - PLUG

19 6672937

  • 6672937 - PLUG
