HOOD ENGINE 5529020114 (1)
1 5529020114
- 5529020114 - HOOD ENGINE
- hood is painted Bobcat white - W/Ref. 4
- 11
- 20 & 21 - Was 5529020082
2 7024438
- 7024438 - SEAL
3 6234028087
- 6234028087 - PLATE
4 1212251011
- 1212251011 - NUT
5 1290707018
- 1290707018 - WASHER
6 6190028137
- 6190028137 - BRACKET
7 5101290955
- 5101290955 - STOP
8 1212251009
- 1212251009 - NUT
9 1307707014
- 1307707014 - WASHER
10 5354604442
- 5354604442 - PLASTIC HANDLE
11 1008707712
- 1008707712 - BOLT
12 1290707014
- 1290707014 - WASHER
13 5354604335
- 5354604335 - HOOD BRACKET
14 1008707018
- 1008707018 - BOLT
15 1290707018
- 1290707018 - WASHER
16 6190028023
- 6190028023 - HINGE
17 1008707318
- 1008707318 - BOLT
18 1343707057
- 1343707057 - WASHER
19 6190028024
- 6190028024 - HINGE
- right
20 6190028025
- 6190028025 - HINGE
- left
21 1360707139
- 1360707139 - PIN
22 1395707017
- 1395707017 - COTTER PIN
23 6190028022
- 6190028022 - HINGE
24 0190028163
- 0190028163 - MOUNT
- threaded plate
25 5354604338
- 5354604338 - COTTER
26 6176028067
- 6176028067 - FLAP
27 6183528011
- 6183528011 - ANGLE PLATE
28 6234028030
- 6234028030 - BRACKET
29 1008707618
- 1008707618 - BOLT
30 5696636604
- 5696636604 - GAS PRESSURE SPRING
- Was 5696636295
