SIDE BLADE 5018001050 (5)

SIDE BLADE 5018001050 (5)

SIDE BLADE 5018001050 (5)

1 5018001050

  • 5018001050 - SIDE BLADE
  • right

2 5018001045

  • 5018001045 - BLADE
  • 600mm - W/Ref. 4
  • 5 & 6

3 5018001063

  • 5018001063 - BLADE
  • 500mm - W/Ref. 4
  • 5 & 6

4 5018001044

  • 5018001044 - BLADE
  • 450mm - W/Ref. 4
  • 5 & 6

5 5018001062

  • 5018001062 - BLADE
  • 300mm - W/Ref. 4
  • 5 & 6

6 5018001046

  • 5018001046 - BLADE
  • 800mm - W/Ref. 4
  • 5 & 6

7 5018001064

  • 5018001064 - BLADE
  • 900mm - W/Ref. 4
  • 5 & 6

8 5455660445

  • 5455660445 - TOOTH
  • BUCKET

9 5455660446

  • 5455660446 - BRACKET

10 5455660447

  • 5455660447 - LOCK

11 0211005045

  • 0211005045 - PIN

12 1395707642

  • 1395707642 - COTTER PIN

13 1309412430

  • 1309412430 - WASHER
