TANK 6733225
1 6733225
- 6733225 - TANK
- Was 6708327
2 6564038
- 6564038 - MOUNT
- VLV
3 25K60204
- 25K60204 - O RING 10
4 6598910
- 6598910 - GAUGE
- FUEL
5 6599455
- 6599455 - VALVE
- shut-off
6 6658180
- 6658180 - PLUG
- BLEED
7 6630041
- 6630041 - ELBOW 90 BARBED
- 3 barbed at one end and one large barb on the other
8 6598908
- 6598908 - ELBOW BARBED
- small one barb at each end of elbow - Was 6681462
9 6598908
- 6598908 - ELBOW BARBED
- small one barb at each end of elbow - Was 6681462
10 7273691
- 7273691 - GROMMET
- 0.375" ID - Was 6553411
11 6564037
- 6564037 - BAND
12 6728472
- 6728472 - INSULATOR TANK
13 84G3716
- 84G3716 - SCREW THD ROLLING TT
14 6559447
- 6559447 - WASHER
15 61D6
- 61D6 - NUT HEX FINISHED GR5
16 6661114
- 6661114 - CAP
- DIESEL 1 PSI
- Green
17 6661696
- 6661696 - CAP
- FUEL LOCKING
- locking - W/Ref. 29 - Was 6654373
18 6650239
- 6650239 - SCREEN
- FUEL PICKUP
- screen covered W/spring
19 1023368
- 1023368 - GROMMET
20 42HS04
- 42HS04 - CLAMP HOSE TYPE M
- Was 6515575
21 5HM13
- 5HM13 - CLAMP CT HOSE
- constant tension
22 6657734
- 6657734 - PUMP
- PRIMER HAND
- barbed fittings for 6
- 35 mm (.25") ID hose - barbed fittings for 6
- 35 mm (.25") ID hose
23 6563505
- 6563505 - CONDUIT
- bulk (5/8'' I.D.) - sold per foot
24 79K5
- 79K5 - O RING 10
- flat boss face
25 99K5
- 99K5 - O-RING
- tapered boss face
26 6715183
- 6715183 - ELBOW 90 STRTHD TUBE
- W/Ref. 24 - check boss face to determine correct replacement o-ring
27 6667353
- 6667353 - FILTER
- FUEL ASSY
- W/Ref. 7
28 6667352
- 6667352 - FILTER
- FUEL W/SEPARATOR 12
29 72F1
- 72F1 - FITTING
30 6661213
- 6661213 - RING
- COMPRESSION
- Use W/Ref. 17
31 6654374
- 6654374 - 2 KEYS
32 6713672
- 6713672 - MOUNT
- ENG
- Engine
33 6565434
- 6565434 - CONDUIT
- bulk (1/2'' I.D.) - sold per foot
34 6578169
- 6578169 - HOSE BULK
- sold per foot - 0.19" ID
35 6577822
- 6577822 - HOSE BULK
- sold per foot
36 6624289
- 6624289 - STRAP
- TIE
37 6577821
- 6577821 - HOSE
- BULK
- sold per foot
38 17C516
- 17C516 - BOLT
- Was 35C000516B
39 57D5
- 57D5 - NUT HEX FLNG GR8
40 6661213
- 6661213 - RING
- COMPRESSION
- Use W/Ref. 9
41 6729855
- 6729855 - TUBE FUEL LINE
- 15.125" (384
- 2mm) long
42 5HM14
- 5HM14 - HOSE CLMP CONST TENS
43 7297009
- 7297009 - KIT FUEL SCREEN PICKUP TUBE
- W/Ref. 10
- 16
- 17
- 28
