BOLT 6513631
1 6513631
- 6513631 - BOLT
2 4E4
- 4E4 - WASHER
3 6512939
- 6512939 - COVER
4 6512940
- 6512940 - SHIM KIT
5 6512938
- 6512938 - SPACER
6 232539
- 232539 - BEARING
7 4E6
- 4E6 - WASHER
8 93G624
- 93G624 - SCREW
9 6513094
- 6513094 - COVER
- SEAL BEARING
10 616791
- 616791 - WASHER
11 17C820
- 17C820 - BOLT 5
12 6512941
- 6512941 - GASKET
13 6513091
- 6513091 - BEARING
14 5J806
- 5J806 - KEY
15 6512929
- 6512929 - YOKE
16 6512932
- 6512932 - SHAFT
17 6512948
- 6512948 - KIT
- BEARING
- spacer
18 6674240
- 6674240 - SPACER
- .137 in.
19 6674241
- 6674241 - SPACER
- .139 in.
20 6674242
- 6674242 - SPACER
- .142 in.
21 6674244
- 6674244 - SPACER
- .148 in.
22 6674245
- 6674245 - SPACER
- .151 in.
23 6674246
- 6674246 - SPACER
- .154 in.
24 6674247
- 6674247 - SPACER
- .157 in.
25 6674248
- 6674248 - SPACER
- .160 in.
26 6674250
- 6674250 - SPACER
- .166 in.
27 6674251
- 6674251 - SPACER
- .169 in.
28 6674249
- 6674249 - SPACER
- .163 in.
29 6598478
- 6598478 - PLATE
- WEAR
30 6513093
- 6513093 - BEARING
31 6519654
- 6519654 - KEY
32 6512942
- 6512942 - SHAFT
- DRIVE HYD
33 6513434
- 6513434 - PLUG
34 79K12
- 79K12 - O RING 10
35 6513433
- 6513433 - SPRING
36 6513432
- 6513432 - POPPET
- Charge Pressure - See Note
37 16F4
- 16F4 - PLUG
38 6513089
- 6513089 - PIN
39 6513092
- 6513092 - PIN
40 6512933
- 6512933 - COUPLER
41 6512949
- 6512949 - O-RING
42 6513434
- 6513434 - PLUG
43 6598902
- 6598902 - PLUG
44 6512946
- 6512946 - SPRING
45 6513090
- 6513090 - SEAL
- SHAFT
46 507695
- 507695 - SNAP RING
47 6512943
- 6512943 - KIT
- SEAL
- Ref. 6
- 14
- 27
- 37 & 41
48 6512935
- 6512935 - COUPLER
49 6512950
- 6512950 - VANE PUMP
- VANE
50 6512934
- 6512934 - SHAFT
51 711054
- 711054 - SNAP RING
