GEAR, RING 6512453
1 6512453
- 6512453 - GEAR
- RING
2 7030192
- 7030192 - SEAL
- rear - Was 6512490
3 6512609
- 6512609 - 2 WASHERS
- thrust - .0025 (0
- 06mm)
4 6512610
- 6512610 - 2 WASHERS
- thrust - .005 (0
- 13mm)
5 6674881
- 6674881 - BEARING SET
- main - Std. - SEE NOTE - One Complete Set - Was 6512445
6 6658848
- 6658848 - PST+R ASY
- (.020 (0
- 51mm)) - W/ Rings
7 6665229
- 6665229 - PISTON ASSEMBLY
- W/Pin & Rings (+.030 (0
- 76mm)) - Was 6512405
8 6656408
- 6656408 - PSTN+RNGS 4
- W/ Rings - (.040 (1
- 02mm))
9 6512409
- 6512409 - 4 RING SE
- Std.
10 6658849
- 6658849 - RG SET(4)
- Complete Set - (.020 (0
- 51mm))
11 6512411
- 6512411 - SET
- RING
- (+.030 (0
- 76mm))
12 6656407
- 6656407 - SET
- RING
- Complete Set - (.040 (1
- 02mm))
13 6666615
- 6666615 - BEARING
- SET
- rod - Std. - Complete Set - Was 6666614
14 6666350
- 6666350 - BEARING
- SET
- rod (-.010 (0
- 25mm)) - Complete Set - Was 6512678
15 6674885
- 6674885 - BEARING SET
- rod (-.020 (0
- 51mm)) - Was 6669571
16 6666614
- 6666614 - BEARING
- SET
- rod (-.030 (0
- 76mm)) - Complete Set - Was 6666615
17 6512641
- 6512641 - 1 KEY
18 6648169
- 6648169 - SEAL
- Was 6648209
19 6558802
- 6558802 - PULLEY
20 18C724
- 18C724 - BOLT
21 1JM4010
- 1JM4010 - DOWEL
22 6512439
- 6512439 - ARM
23 6512438
- 6512438 - TENSIONER
- timing chain
24 6661790
- 6661790 - PIN
- Was 6512440
25 17C746
- 17C746 - BOLT
- Main
26 6512920
- 6512920 - 5 DOWELS
27 6598356
- 6598356 - BUSHING
- one bushing
