720.0
/
VALVE, SECTION 6650703

VALVE, SECTION 6650703

VALVE, SECTION 6650703

1 6650703

  • 6650703 - VALVE
  • SECTION

2 6650695

  • 6650695 - LOAD CK.

3 7030462

  • 7030462 - BOLT
  • Was 89G414

4 89G408

  • 89G408 - BOLT

5 6519941

  • 6519941 - PLATE
  • RETAINER

6 6650693

  • 6650693 - RETAINER

7 6647691

  • 6647691 - BONNET

8 6650696

  • 6650696 - SEAL KIT
  • Ref. 3-5

9 6647694

  • 6647694 - SEAL KIT
  • Ref. 11 & 12
