BOLT 29G444 (1)
1 29G444
- 29G444 - BOLT
2 6589564
- 6589564 - RETAINER
3 6587763
- 6587763 - BOOT
4 6812031
- 6812031 - SPOOL LOCK BLOCK
- lock - Was 6805657
5 29G416
- 29G416 - BOLT
6 6814511
- 6814511 - SPOOL
- LIFT
- Was 6674808
7 6815152
- 6815152 - SPOOL
- TILT
- Was 6674814
8 7300937
- 7300937 - SPOOL AUX
- auxiliary - Was 6588074
9 6592115
- 6592115 - SEAT
- load check
10 6592117
- 6592117 - SPRING
- LOAD CHECK
11 79K8
- 79K8 - O RING 10
12 6592116
- 6592116 - NUT
- load check
13 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check -W/Ref. 16-18
14 79K10
- 79K10 - O RING 10
15 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
16 58K014
- 58K014 - O-RING 10
- back-up washer required
17 6677106
- 6677106 - O-RING
- back-up washer not required
18 6596569
- 6596569 - SEAT
- aux. load check
19 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
20 58K017
- 58K017 - O-RING 10
21 6665569
- 6665569 - RING
- BACK-UP
- back-up
22 25K20016
- 25K20016 - O RING 10
23 6665570
- 6665570 - CLYD RING
- glide
24 6595663
- 6595663 - BUSHING
25 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
26 6587580
- 6587580 - SPRING
27 6592100
- 6592100 - COLLAR
28 6596807
- 6596807 - PLUG
- plastic - 0.46" long
29 6586918
- 6586918 - SCREW
- DETENT
30 6587575
- 6587575 - ADAPTER
31 6592107
- 6592107 - SPRING
- DETENT 5
32 6592105
- 6592105 - BALL 5
33 6531270
- 6531270 - SLEEVE
- DETENT
34 6592098
- 6592098 - WASHER
35 799119
- 799119 - RING
36 6589226
- 6589226 - COVER
- END
- 0.63" flange
37 6660644
- 6660644 - CAP
38 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
39 30G416
- 30G416 - BOLT
40 6592109
- 6592109 - ADAPTER
41 6683274
- 6683274 - SEAL
- SPOOL 10
- - spool - Was 6665846
42 6588781
- 6588781 - END CAP
43 58K124
- 58K124 - O RING 10
44 6596332
- 6596332 - SPRING
45 7108780
- 7108780 - SLEEVE
- Was 6595951
46 6592720
- 6592720 - PLUG
- W/Ref. 16-18
47 1K127
- 1K127 - O-RING 10
- Was 93K127
48 7202038
- 7202038 - BUSHING
- ALIGNMENT
- Also Order 82K019 alignment O-ring - Was 6805102
49 90K8
- 90K8 - PLUG
- W/Ref. 51 - socket head - flat boss face
50 95K12
- 95K12 - O-RING
- tapered boss face - Was 99K000012B
51 75K12
- 75K12 - O'RING 10
- flat boss face
52 99K6
- 99K6 - O-RING
- tapered boss face
53 79K6
- 79K6 - O RING 10
- flat boss face
54 6662848
- 6662848 - CAP
55 6817552
- 6817552 - CROSS
- W/Ref. 52 - flat boss face - Was 6805241
56 97K6
- 97K6 - O-RING
- flared end
57 6577690
- 6577690 - TUBELINE
58 6676029
- 6676029 - SOLENOID
- LOCK SPOOL
- 127 mm (5") wire - W/Ref. 13 - 3-pin connector - Order for production valve
59 6665084
- 6665084 - VALVE
- SOLENOID
- solenoid - W/Ref. 58 & 59 - Was 6653395
60 6586459
- 6586459 - SEAL KIT
61 6666616
- 6666616 - VALVE
- STEM SOLENOID
62 79K7
- 79K7 - O RING 10
63 6717706
- 6717706 - COIL
- 10 VOLT
- 10 volt - W/Nut - Was 6665759
64 6676566
- 6676566 - NUT
65 6678574
- 6678574 - VALVE
- RELIEF
- optional - port relief & anti-cav. W/Ref. 16-18 - 3500 PSI - use in tilt cylinder base end port - Was 6673184
66 55K204
- 55K204 - O RING 10
67 55K212
- 55K212 - O RING 10
68 6806007
- 6806007 - SPRING
69 54K20002
- 54K20002 - O'RING 10
70 6816252
- 6816252 - SEAL KIT
- one spool - Ref. 2
- 4
- 29
- 42
- 48 & 64 - Was 6806941
71 6632279
- 6632279 - KIT
- SEAL
- main relief - Ref. 21-24
72 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 16-18 - Was 6586461
73 6816253
- 6816253 - KIT
- SEAL
- complete - Ref. 2
- 4
- 6
- 13
- 16-18
- 21-24
- 42
- 44
- 48
- 52
- 58
- 61 & 62 - Was 6809448
