FITTING 1321499 (1)
1 1321499
- 1321499 - FITTING
- W/Ref. 2 - Was 6567884
2 79K16
- 79K16 - O RING 10
3 6703885
- 6703885 - HOSE
4 6705161
- 6705161 - TUBE
5 42H16
- 42H16 - CLAMP
- HOSE 5
6 17C724
- 17C724 - BOLT
7 83D7
- 83D7 - NUT
8 6703722
- 6703722 - ARM
- torgue
9 85D6
- 85D6 - NUT PRETRQ HEX LOCK
10 17C620
- 17C620 - BOLT
11 17C616
- 17C616 - BOLT 5
12 62D6
- 62D6 - NUT HEX FINISHED GR5
13 6703719
- 6703719 - ROD
14 6512954
- 6512954 - ROD END
- R.H. threads
15 6704016
- 6704016 - MOUNT
16 84G3712
- 84G3712 - SCREW THD ROLLING TT
17 35C516
- 35C516 - SCREW HEX HD W/F GR5
18 83D5
- 83D5 - LKNUT HEX FLG GR8
19 6705129
- 6705129 - MOUNT
20 6705112
- 6705112 - MOUNT
21 17C720
- 17C720 - BOLT
- Was 17C000716B
22 17C524
- 17C524 - BOLT
23 25E15
- 25E15 - WASHER FLAT PLAIN
24 6705780
- 6705780 - PULLEY
25 25E21
- 25E21 - WASHER FLAT PLAIN
26 62D8
- 62D8 - NUT
27 17K7
- 17K7 - ELBOW
- W/Ref. 31
28 79K10
- 79K10 - O RING 10
29 6705497
- 6705497 - HOSE
30 6662695
- 6662695 - VALVE
- control - W/Ref. 31
31 763818
- 763818 - ELBOW
- W/Ref. 31
32 79K12
- 79K12 - O RING 10
33 30H40
- 30H40 - CLAMP
34 85D8
- 85D8 - NUT PRETRQ HEX LOCK
35 17C816
- 17C816 - BOLT
36 6705442
- 6705442 - HOSE
37 36K7
- 36K7 - FITTING
38 6703483
- 6703483 - PULLEY
- FAN DRIVE IDLER
39 6704607
- 6704607 - BELT
- FAN
40 6705168
- 6705168 - MOUNT
41 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
42 6632279
- 6632279 - KIT
- SEAL
- relief
43 6705471
- 6705471 - MOUNT
44 35C610
- 35C610 - BOLT 5
45 6708307
- 6708307 - SHIELD
46 6704720
- 6704720 - BELT
- ALT
- alt./gear pump
