Bobcat
/
753.0
/
KIT, ACS CONVERSION 6731150

KIT, ACS CONVERSION 6731150

KIT, ACS CONVERSION 6731150

1 6731150

  • 6731150 - KIT
  • ACS CONVERSION
  • foot control - Ref. 2-30 - loader must be equipped W/advanced hand control option

2 6680470

  • 6680470 - SPRING
  • Was 6675745

3 6684912

  • 6684912 - SENSOR
  • FOOT RH
  • Was 6680420

4 6676029

  • 6676029 - SOLENOID
  • LOCK SPOOL

5 6684911

  • 6684911 - SENSOR
  • FOOT LH
  • Was 6680421

6 6676029

  • 6676029 - SOLENOID
  • LOCK SPOOL

7 6676537

  • 6676537 - SWITCH

8 6680477

  • 6680477 - STRAP
  • Was 6719715

9 6680468

  • 6680468 - STRAP
  • solenoid - Was 6719716

10 6719834

  • 6719834 - SPACER
  • threaded - Was 6719835

11 7126869

  • 7126869 - BRACKET
  • Was 6726573

12 6726681

  • 6726681 - LINK
  • AFC POD

13 6727065

  • 6727065 - SCREW

14 6727496

  • 6727496 - PIN

15 6727926

  • 6727926 - DECAL
  • OPERATION
  • hand & foot controls

16 6728539

  • 6728539 - DECAL
  • WARNING

17 6733430

  • 6733430 - HARNESS
  • Was 6729023

18 6729467

  • 6729467 - SPACER
  • COLLAR

19 6680469

  • 6680469 - SPACER
  • threaded - Was 6729600

20 17C608

  • 17C608 - BOLT

21 17C612

  • 17C612 - SCREW HEX CAP

22 25E13

  • 25E13 - WASHER FLAT PLAIN

23 30H38

  • 30H38 - CLIP

24 17C514

  • 17C514 - BOLT

25 37C620

  • 37C620 - BOLT CARRIAGE

26 61D6

  • 61D6 - NUT HEX FINISHED GR5
  • Was 57D6

27 95D5

  • 95D5 - NUT

28 95D6

  • 95D6 - NUT HEXAGON

29 6676029

  • 6676029 - SOLENOID
  • LOCK SPOOL

30 7123941

  • 7123941 - PEDAL ASSEMBLY

31 7123942

  • 7123942 - PEDAL ASSEMBLY

32 6727926

  • 6727926 - DECAL
  • OPERATION
  • Was6727941

33 6901492

  • 6901492 - INSTRUCTIONS
