MAINFRAME 6737360 (2)
1 6737360
- 6737360 - MAINFRAME
2 6727837
- 6727837 - COVER
- 2 hole mount - 5.16" x 2.25" - Was 6704860
3 84G3712
- 84G3712 - SCREW THD ROLLING TT
4 6708987
- 6708987 - HINGE
- WELD-ON
- tailgate
5 6708987
- 6708987 - HINGE
- WELD-ON
- Use W/Ref. 11
6 6680970
- 6680970 - VENT BREATHER
- WAS 6670627
7 6700330
- 6700330 - COVER
8 6731121
- 6731121 - PLUG RECESSED PIPE
- chaincase fill - Was 11F000012B
9 6702584
- 6702584 - BUSHING
- WELD-ON
- weld on
10 6702583
- 6702583 - BUSHING
- WELD-ON
11 6577394
- 6577394 - HINGE
- hinge - top - weld on
12 6555987
- 6555987 - BUSHING
- weld on
13 31C824
- 31C824 - BOLT 10
14 31C820
- 31C820 - BOLT
15 6706042
- 6706042 - COVER
16 6733701
- 6733701 - COVER
- Was 6704695
17 6700182
- 6700182 - COVER
- DRAIN
18 6706485
- 6706485 - BRACKET
- tie down - weld-on
19 6599645
- 6599645 - PLUG
- STEEL
- chaincase drain
20 6553411
- 6553411 - BUSHING
- PRESS FIT 5
21 83D8
- 83D8 - LKNUT HEX FLG GR8
22 6701097
- 6701097 - WASHER
- 1" x .519" ID
23 6578505
- 6578505 - COVER
24 6714361
- 6714361 - COUNTERWEIGHT
- AXLE
- front - 71
- 6 kg (38.7 lb) - 114
- 3 mm (4.5") wide
25 17C640
- 17C640 - BOLT
26 61D6
- 61D6 - NUT HEX FINISHED GR5
27 84G3110
- 84G3110 - SCREW
- RH side - 5/16 x .62"
28 84G3112
- 84G3112 - SCREW THD ROLLING TT
- LH side - 5/16 x .75"
29 84G3710
- 84G3710 - SCREW
- 3/8 x .62"
30 17C620
- 17C620 - BOLT
- Was 6717378
31 6734420
- 6734420 - COVER
32 6727837
- 6727837 - COVER
33 6727837
- 6727837 - COVER
34 6734420
- 6734420 - COVER
35 6718796
- 6718796 - PLUG
