LEVER 6702786 (2)
1 6702786
- 6702786 - LEVER
- Use W/Ref. 11 (6658613 Cable)
2 6707349
- 6707349 - LEVER
- Use W/Ref. 11 (6666379 Cable)
3 6702621
- 6702621 - HANDLE GRIP
- Use W/Ref. 11 (6658613 Cable)
4 6707367
- 6707367 - GRIP
- Use W/Ref. 11 (6666379 Cable)
5 6702990
- 6702990 - BUSHING
- bronze sleeve
6 6702787
- 6702787 - LEVER
- Use W/Ref. 11 (6658613 Cable)
7 6707351
- 6707351 - LEVER
- Use W/Ref. 11 (6666379 Cable)
8 6702791
- 6702791 - LEVER
- Use W/Ref. 11 (6658613 Cable)
9 6707352
- 6707352 - LEVER
- Use W/Ref. 11 (6666379 Cable)
10 6702775
- 6702775 - LEVER
- throttle - not used on 6708345 Kit
11 6631036
- 6631036 - BALLJOINT
12 8D4
- 8D4 - NUT
13 86D4
- 86D4 - NUT
14 6658613
- 6658613 - CABLE
- 31.5" (800
- 1 mm) long
15 6666379
- 6666379 - CABLE
- 33.5" (850
- 9 mm) long
16 4F4051
- 4F4051 - PIN
17 6513495
- 6513495 - PIN 5
18 2J4200
- 2J4200 - CLEVIS
19 6592766
- 6592766 - U-BOLT
20 83D5
- 83D5 - LKNUT HEX FLG GR8
21 6706420
- 6706420 - MOUNT
- cable - Was 6702778
22 6706421
- 6706421 - MOUNT
- cable - Was 6702777
23 85D6
- 85D6 - NUT PRETRQ HEX LOCK
24 6702776
- 6702776 - STEP
25 57D6
- 57D6 - NUT HEX FLNG GR8
26 37C620
- 37C620 - BOLT CARRIAGE
- carriage
27 6706281
- 6706281 - BELLCRANK
- W/Ref. 26 - Was 6704292
28 58K014
- 58K014 - O-RING 10
29 6702782
- 6702782 - BRG SLEV.
- bronze - Not in Kit
30 6655781
- 6655781 - BEARING
- THRUST
- thrust
31 38C816
- 38C816 - BOLT
- shoulder
32 6563914
- 6563914 - WASHER
33 38C610
- 38C610 - SCREW SHOULDER
- Was 6704285
34 85D4
- 85D4 - NUT 5
35 6702774
- 6702774 - LINK
- TILT
- tilt
36 38C606
- 38C606 - BOLT
- shoulder
37 6658682
- 6658682 - BEARING
- swivel
38 17C410
- 17C410 - BOLT 10
39 6702773
- 6702773 - LINK
- LIFT
- lift
40 6658930
- 6658930 - BOOT
41 25G612
- 25G612 - SCREW
- socket hex head
42 6703724
- 6703724 - DECAL
- WARNING
- operating
43 6703726
- 6703726 - DECAL
- WARNING
- warning
44 6703678
- 6703678 - OHB
- W/WIRE ROPE
- W/wire rope
45 6558309
- 6558309 - CABLE BULK/FT
- bulk - sold per foot - Also Order (2) of 6558310 sleeve
46 6558310
- 6558310 - SLEEVE
- wire rope
47 6724033
- 6724033 - HC O/M
- operator - Was 6900369
48 6703725
- 6703725 - DECAL
- WARNING
- warning
49 38C612
- 38C612 - BOLT
50 59D6
- 59D6 - NUT LOCK HEX PT
51 6680412
- 6680412 - HANDLE DLX LEFT
- LH - deluxe - multi switch - Was 6707976
52 6640690
- 6640690 - PIN
53 6640691
- 6640691 - TERMINAL
54 6641176
- 6641176 - SEAL
55 6662257
- 6662257 - PIN
56 6706568
- 6706568 - KIT
- HANDLE
- Multi-switch - L.H. - Includes Ref. 46-53
57 6680447
- 6680447 - DECAL
- Was 6677370
58 6641179
- 6641179 - CONNECTOR METRI PACK
- 2-pin
59 6640699
- 6640699 - CONNECTOR METRI PACK
- 3-pin
60 6641178
- 6641178 - CONNECTOR METRI PACK
- 2-pin
61 6664599
- 6664599 - CONNECTOR 3 PIN
- 3-pin triangle
62 6664800
- 6664800 - LOCK SECONDARY
- 3-pin triangle
63 6640700
- 6640700 - LOCK METRI PACK
- 3-pin
64 6641180
- 6641180 - LOCK METRI PACK
- Use W/ 2-pin connector
65 6641173
- 6641173 - CONNECTOR
- 6-pin
66 6641181
- 6641181 - LOCK
- 6-pin
67 6680413
- 6680413 - HANDLE
- SWITCH DLX
- RH - multi switch - Was 6706340
68 6640690
- 6640690 - PIN
69 6641176
- 6641176 - SEAL
70 6706567
- 6706567 - KIT
- HANDLE DLX RH
- RH - multi switch - Ref. 47
- 48 & 52-56
71 6704454
- 6704454 - HANDLE
- CONTROL ELEC ASSY
- Cobra style
72 6666534
- 6666534 - SEAL CABLE
73 6722847
- 6722847 - INSTRUCTIONS
- Was 6720917
