NUT PRETRQ HEX LOCK 85D8 (5)
1 85D8
- 85D8 - NUT PRETRQ HEX LOCK
2 35C620
- 35C620 - BOLT 5
3 6652918
- 6652918 - NUT
4 6705106
- 6705106 - WASHER 5
5 6661785
- 6661785 - MOUNT ENGINE
6 6706043
- 6706043 - SPACER
7 6661787
- 6661787 - WASHER SNUBBING
8 742640
- 742640 - WASHER
- .25" thick - Use W/Ref. 43 (17C-830 Bolt)
9 6716408
- 6716408 - SPACER
- .40" thick - Use W/Ref. 43 (47C-832 Bolt)
10 6728337
- 6728337 - SPACER
- .58" thick - Use W/Ref. 43 (6675221 Bolt)
11 6734432
- 6734432 - SPACER
- 1.0" thick
12 43C852
- 43C852 - BOLT
- Was 43C000848B
13 83D8
- 83D8 - LKNUT HEX FLG GR8
14 25E21
- 25E21 - WASHER FLAT PLAIN
- Use 2 max.
15 6719827
- 6719827 - BOLT
- Was 6CM01225B
16 84G3712
- 84G3712 - SCREW THD ROLLING TT
17 7104568
- 7104568 - MOUNT
- engine & hyd. pump - for horizontal hardware mounting of hydrostatic pump - Was 6712161
18 35C516
- 35C516 - SCREW HEX HD W/F GR5
19 1CM870
- 1CM870 - BOLT
20 29CM820
- 29CM820 - SCREW FLNGE HEX CAP
- 90 amp. alt.
21 57D5
- 57D5 - NUT HEX FLNG GR8
22 85D6
- 85D6 - NUT PRETRQ HEX LOCK
23 6568877
- 6568877 - WASHER
24 1CM890
- 1CM890 - BOLT
25 6562257
- 6562257 - BRACKET
- ALT
26 17C556
- 17C556 - BOLT
27 17C648
- 17C648 - SCREW HEX CAP
28 6704720
- 6704720 - BELT
- ALT
- alternator
29 6675837
- 6675837 - BELT
- ALT
- 90 amp
30 36K6
- 36K6 - CAP
31 6704012
- 6704012 - HOSE
32 15KB0808
- 15KB0808 - FTG HYD S CONNECTOR
- W/Ref. 30 - flat boss face
33 97K8
- 97K8 - O-RING
- flared end
34 99K8
- 99K8 - O-RING
- tapered boss face
35 79K8
- 79K8 - O RING 10
- flat boss face
36 6700535
- 6700535 - SPACER
37 6703981
- 6703981 - MOUNT
- W/Ref. 32
38 6719828
- 6719828 - BOLT
- Was 6CM01230B
39 6704322
- 6704322 - MOUNT
- fuel filter
40 6719826
- 6719826 - BOLT
- Was 5CM01035B
41 6719829
- 6719829 - BOLT
- Was 6CM01235B
42 6705711
- 6705711 - BRACKET
43 6727084
- 6727084 - BRACKET
- alt. - 90 amp.
44 84G3716
- 84G3716 - SCREW THD ROLLING TT
45 6654139
- 6654139 - MOULDING BULK/FT
- sold per foot
46 17C830
- 17C830 - BOLT
- hyd. pump mount - 1.875" long
47 47C832
- 47C832 - BOLT
- hyd. pump mount - 2" long
48 6675221
- 6675221 - BOLT
- hyd. pump mount - 2.25" long
49 6703140
- 6703140 - WASHER
50 17C828
- 17C828 - BOLT
- hyd pump mount
51 6731060
- 6731060 - SHIELD
- bolts to frame - Was 6717812
52 6675838
- 6675838 - BUSHING
- ALTNTR BRKT
- 90 amp. alt.
53 6725427
- 6725427 - BRACKET
- ALT
- 90 amp. alt.
54 1CM8100
- 1CM8100 - SCREW HEX CAP
55 53DM8
- 53DM8 - NUT HX THDLK PREAPPL
56 6E5
- 6E5 - WASHER INTL T LOCK
- 90 amp. alt.
