843.0
/
PUSH ROD 6599231

PUSH ROD 6599231

PUSH ROD 6599231

1 6599231

  • 6599231 - PUSH ROD
  • Was 997940B

2 799119

  • 799119 - RING

3 997942

  • 997942 - ARM
  • rocker

4 85D5

  • 85D5 - NUT PRETRQ HEX LOCK

5 997943

  • 997943 - ADJUSTER

6 6599229

  • 6599229 - BRACKET
  • Was 997938B

7 3490714

  • 3490714 - PLUG

8 997936

  • 997936 - SHAFT
  • rocker - W/Ref. 16 - Was 6599227

9 3725381

  • 3725381 - NUT

10 18C894

  • 18C894 - SCREW

11 6599180

  • 6599180 - KEEPER
  • Was 997953

12 6599221

  • 6599221 - WASHER
  • Was 997954

13 6599224

  • 6599224 - DEFLECTOR
  • Was 997952B

14 6599222

  • 6599222 - SPRING
  • Was 997948B

15 997951

  • 997951 - SEAT

16 6599197

  • 6599197 - CAP
  • Was 6598520

17 997930

  • 997930 - PLUG

18 998287

  • 998287 - BUSHING

19 997931

  • 997931 - PLUG

20 18C510

  • 18C510 - BOLT

21 23E5

  • 23E5 - L WASHER
  • Was 2E000005B

22 6668044

  • 6668044 - GASKET
  • Was 997934B

23 997958

  • 997958 - DOWEL
  • locator

24 997946

  • 997946 - VALVE
  • exhaust

25 6599235

  • 6599235 - PLATE
  • Was 997941B

26 6J606

  • 6J606 - KEY
  • WOODRUFF

27 6599234

  • 6599234 - GEAR
  • Was 997945B

28 6599259

  • 6599259 - WASHER
  • Was 998290B

29 18C822

  • 18C822 - SCREW
