VALVE 6592740 (2)
1 6592740
- 6592740 - VALVE
- Ref. 2-10
- 37
- 49 & 50 - See Service Letter
2 73G410
- 73G410 - SCREW
3 22E4
- 22E4 - WASHER
4 6589564
- 6589564 - RETAINER
5 6666582
- 6666582 - SPOOL BOM
- lift - #1 or red - SEE NOTE
6 6666583
- 6666583 - SPOOL BOM
- lift - #2 or green - SEE NOTE
7 6666584
- 6666584 - SPOOL BOM
- lift - #3 or black - SEE NOTE
8 6666587
- 6666587 - SPOOL
- TILT
- tilt - #3 or black - SEE NOTE
9 6666586
- 6666586 - SPOOL
- TILT
- tilt - #2 or green - SEE NOTE
10 6666585
- 6666585 - SPOOL
- TILT
- tilt - #1 or red - SEE NOTE
11 6592119
- 6592119 - SPOOL
- auxiliary - SEE NOTE
12 6592720
- 6592720 - PLUG
- W/Ref. 12-14
13 79K10
- 79K10 - O RING 10
14 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
15 58K014
- 58K014 - O-RING 10
- back-up washer required - Was 25K20016
16 6677106
- 6677106 - O-RING
- BACK-UP WASHER NOT REQUIRED
17 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity - W/Ref. 12-14 - SEE NOTE - Was 6661345
18 6592115
- 6592115 - SEAT
19 6592117
- 6592117 - SPRING
- LOAD CHECK
20 79K8
- 79K8 - O RING 10
21 6592116
- 6592116 - NUT
- load check
22 6592111
- 6592111 - ORIFICE
- .161/.154
23 6593680
- 6593680 - RETAINER
24 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
25 6599161
- 6599161 - VALVE
- RELIEF
- W/Ref. 12-14 - SEE NOTE
26 799119
- 799119 - RING
27 6592098
- 6592098 - WASHER
28 6588163
- 6588163 - SCREW
- Was 69G000412B
29 6592094
- 6592094 - BONNET
30 6592096
- 6592096 - SLEEVE
- lift
31 6587575
- 6587575 - ADAPTER
- Was 6592099
32 6592107
- 6592107 - SPRING
- DETENT 5
33 6592105
- 6592105 - BALL 5
34 6586918
- 6586918 - SCREW
- DETENT
- Was 6535747
35 6596807
- 6596807 - PLUG
- plastic - 0.46" long
36 54K20002
- 54K20002 - O'RING 10
37 6592100
- 6592100 - COLLAR
38 6587580
- 6587580 - SPRING
- Was 6592106
39 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
40 6592109
- 6592109 - ADAPTER
41 69G414
- 69G414 - BOLT
- Was 6588164
42 74G416
- 74G416 - SCREW
43 6593349
- 6593349 - SLEEVE
- auxiliary
44 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Order Ref. 42
- 45 & 48 - Was 6587633
45 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Order Ref. 42
- 45 & 48
46 6587763
- 6587763 - BOOT
- Was 6583727
47 6532633
- 6532633 - RESTRICTOR
- 0.153
48 6662848
- 6662848 - CAP
49 6592103
- 6592103 - BUSHING
- See Service Letter dated 5 Jan. 87
50 6538466
- 6538466 - BUSHING
- With part # stamped on face - Was 6534866
51 6665089
- 6665089 - SEAL 5
- lip seal - Was 6659554
52 6646372
- 6646372 - SEAL
- QUAD RING
- quad ring seal
53 6665846
- 6665846 - SEAL 5
- Use W/Ref. 53
54 6664373
- 6664373 - VALVE
- RELIEF
- optional port relief & anti cav. W/Ref. 12 - Use in tilt cylinder base end port
55 6816251
- 6816251 - KIT
- SEAL
- - Ref. 12-14
- 18
- 22-25
- 37
- 46
- 50 & 53 - Was 6816717
56 6816250
- 6816250 - KIT
- SEAL
- Ref. 30
- 46
- 49 & 50 - For One Spool - Was 6803605
57 6661328
- 6661328 - SEAL KIT
- main relief seal - Ref. 22-25
58 6809425
- 6809425 - SEAL KIT
- Upper Deck - Ref. 12-14 & 18 - Was 6586461
59 1K127
- 1K127 - O-RING 10
- Was 93K127
