WASHER 4E8

WASHER 4E8

WASHER 4E8

1 4E8

  • 4E8 - WASHER

2 61D8

  • 61D8 - NUT 5

3 633157

  • 633157 - PIN

4 6546711

  • 6546711 - FRAME

5 17C648

  • 17C648 - SCREW HEX CAP

6 6546749

  • 6546749 - PIN

7 81D6

  • 81D6 - NUT

8 6501706

  • 6501706 - HANDLE
  • R.H.

9 6503955

  • 6503955 - SPACER
  • TUBE

10 17C828

  • 17C828 - BOLT

11 17C880

  • 17C880 - BOLT

12 6503954

  • 6503954 - ARM

13 6548500

  • 6548500 - TUBE

14 6503956

  • 6503956 - SPRING

15 6547130

  • 6547130 - WEDGE
  • locking - R.H.

16 25E22

  • 25E22 - WASHER

17 6547129

  • 6547129 - WEDGE
  • locking - L.H.

18 6501689

  • 6501689 - HANDLE
  • L.H.

19 6590118

  • 6590118 - BOB-TACH
  • ALSO ORDER 6561383 DECAL - WAS SALES

20 6547650

  • 6547650 - COLLAR
  • Weld-on

21 6547649

  • 6547649 - COLLAR
  • Weld-on
