NUT 7008988 (1)

NUT 7008988 (1)

NUT 7008988 (1)

1 7008988

  • 7008988 - NUT
  • Was 6697462

2 7012834

  • 7012834 - VALVE
  • JOYSTICK
  • Ref. 39-45 - Was 7000453

3 7002252

  • 7002252 - HANDLE
  • JOYSTICK

4 7002250

  • 7002250 - HOUSING
  • JOYSTICK

5 6696332

  • 6696332 - PIN

6 7000818

  • 7000818 - O-RING

7 7000819

  • 7000819 - SPACER

8 7000820

  • 7000820 - BOLT

9 7000821

  • 7000821 - BOLT

10 7000822

  • 7000822 - WASHER
  • SPRING

11 7000823

  • 7000823 - CAP
  • END

12 7000813

  • 7000813 - WASHER
  • SEALING

13 7000825

  • 7000825 - BRACKET
  • SELECTOR

14 7000826

  • 7000826 - CONNECTOR

15 7000827

  • 7000827 - PISTON
  • VALVE JOYSTICK

16 7000828

  • 7000828 - BOOT
  • RUBBER

17 7002328

  • 7002328 - CABLE
  • PUSH-PULL

18 6695575

  • 6695575 - BOLT

19 6697775

  • 6697775 - WASHER SPRING

20 7002912

  • 7002912 - TUBELINE
  • HYD

21 6694136

  • 6694136 - O-RING

22 6697056

  • 6697056 - BOLT

23 6696165

  • 6696165 - BOLT JOINT

24 6694137

  • 6694137 - O-RING

25 7002235

  • 7002235 - TUBELINE
  • HYD

26 6694137

  • 6694137 - O-RING

27 6696165

  • 6696165 - BOLT JOINT

28 6694137

  • 6694137 - O-RING

29 6696165

  • 6696165 - BOLT JOINT

30 6694137

  • 6694137 - O-RING

31 7002231

  • 7002231 - TUBELINE
  • HYD

32 6695562

  • 6695562 - BOLT JOINT

33 7002230

  • 7002230 - HOSE
  • RETURN

34 7000814

  • 7000814 - CLAMP
  • HOSE

35 6695525

  • 6695525 - BOLT

36 6697774

  • 6697774 - WASHER

37 6697775

  • 6697775 - WASHER SPRING

38 6696449

  • 6696449 - PLUG

39 6696890

  • 6696890 - VALVE RELIEF

40 6696725

  • 6696725 - SPOOL

41 6696726

  • 6696726 - SPOOL
  • Use W/O front aux hyd

42 7178632

  • 7178632 - SPOOL
  • VALVE
  • Use W/front aux hyd

43 7192353

  • 7192353 - BONNET
  • DETENT HYD VALVE
  • Use W/front aux hyd

44 7178633

  • 7178633 - BONNET
  • DETENT HYD VALVE
  • Use W/front aux hyd

45 6696448

  • 6696448 - PLUG
